This series of single cylinder diesel engines are manufactured by Kaiao Power.
Brief introduction:
Customized
The engines are designed and manufactured from users’ perspective for installation dimension,main parts and wearing parts.
Reasonable
Light weight and compact design,suit for wide application scope,such as agricultural equipment,garden machinery,engineering machines... .
Main features: single cylinder,4 stroke,vertical,air cooled.Equip with muffler,reduce a lot of noise from exhaust noise.The design of cylinder block,engine cover and valve train can reduce noise level.
Economic and less noise
This type is the smallest type of this series.High Compression ratio,high efficiency.Low fuel consumption rate till 285g/kw.h.The muffler system greatly lowers exhaust noise.With the addition of advanced design air induction system,intake noise is reduced to a low level.
Advanced
Unique gear drive is adopted in the engine,which can reduce noise and vibration of the engine.It can bear many hard working conditions.
The fuel system assures high efficiency operation:Precision machined and precisely timed injection pump and direct-injection design leads to lower fuel consumption and reduced tailpipe emissions.
Others
The engine can start by recoil or electric ,easy and fast.
All the engines achieve CE, ISO90001 and many domestic standards.
.
Parameter:
| Model | KA170F |
| Rated output(HP/rpm) | 3.4HP/3000rpm 3.8HP/3600rpm |
| Rated output(KW/rpm) | 2.5KW/3000rpm 2.8KW/3600rpm |
| Engine type | Single cylinder, vertical, four-stroke, air-cooled, direct injection |
| Diameter*stroke(mm) | 70X55 |
| Piston displacement (L) | 0.211 |
| Compression ratio | 20 |
| Rated speed(rpm) | 3000/3600 |
| Max. no-load speed(r/min) | 108% of Rated rotary speed |
| Min. no-load speed(r/min) | 1300 |
| Lubrication system | Pressure splash Type |
| Engine starting system | Recoil starter or Electric starter |
| Output terminal rotation | AnticlockWise |
| Fuel oil model | Summer:0#, Winter:-10# |
| Fuel tank capacity (L) | 2.5 |
| Fuel consumption rate(g/kW.h) | 280.2/3000 288.3/3600 |
| Oil consumption rate(g/kW.h) | 4.08 |
| Oil grade | CD grade or SAE10W-30,15W-40 |
| Valve clearance(cold state) mm | 0.10-0.15 |
| Lube oil capacity (L) | 0.75 |
| Starting motor (V,kW) | 12V 0.8kW |
| Charging generator(V,A) | 12V 3A |
| Battery capacity(V,AH) | 12V-24AH-36AH |
| Dimension (L*W*H)(mm) | 450*390*480 |
| Net weight(kg) | 27 |
