8hp/3000rpm Single Cylinder Hand Starting Diesel Motor
- FOBSHANGHAI
- T/T
You May Like
Product Details
| Condition | New | Usage | Other, Generator | |
| Fuel | Diesel | Stroke | 4 Stroke | |
| Cylinder | Single Cylinder | Cold Style | Other, Air-cooled | |
| Start | Other, New hand starter | Place of Origin | Jiangsu, China | |
| Brand Name | Kaiao | Model Number | KA186 | |
| Dimension(L*W*H) | 520*450*570mm | Weight | 55kg | |
| Certification | ISO,CE,SGS |
Product Description
8hp/3000rpm Single Cylinder Hand Starting Diesel Motor
This series of single cylinder diesel engines with new hander starter are manufactured by Kaiao Power.
Brief introduction:
Customized
The engines are designed and manufactured from users’ perspective for installation dimension,main parts and wearing parts.
Economic
This type is the Hotsale type of this series.High Compression ratio,high efficiency.Low fuel consumption rate till 271g/kw.h.Equip with small fuel injection system,achieve more sufficient burning.
Advanced
Unique gear drive is adopted in the engine,which can reduce noise and vibration of the engine.It can bear many hard working conditions.
Reasonable
Light weight and compact design,suit for wide application scope,such as agricultural equipment,garden machinery,engineering machines... .
Main features: single cylinder,4 stroke,vertical,air cooled.Equip with muffler,reduce a lot of noise from exhaust noise.The design of cylinder block,engine cover and valve train can reduce noise level.
Others
The engine can start by recoil or electric ,easy and fast.
All the engines achieve CE, ISO90001 and many domestic standards.
New patented hand starter,manpower-saving and easy maintence.
Parameter:
| Model | KA186F |
| Rated output(HP/rpm) | 7.6HP/3000, 8.4HP/3600 |
| Rated output(KW/rpm) | 5.7KW/3000, 6.3KW/3600 |
| Engine type | Single-cylinder, vertical, four-stroke, air-cooled, direct injection |
| Cylinder Diameter*stroke(mm) | 86X70 |
| Piston displacement (L) | 0.406 |
| Compression ratio | 19 |
| Max. no-load speed(r/min) | 108% of Rated rotary speed |
| Min. no-load speed(r/min) | 1300 |
| Lubrication system | Pressure splash complex Type |
| Engine starting system | Recoil starter or Electric starter |
| Output terminal rotation | AnticlockWise |
| Fuel oil model | Summer:0#, Winter:-10# |
| Fuel tank capacity (L) | 5.5 |
| Fuel consumption rate(g/kW.h) | 275.1/3000 281.5/3600 |
| Oil consumption rate(g/kW.h) | 4.08 |
| Oil grade | CD grade or SAE10W-30,15W-40 |
| Valve clearance(cold state) mm | 0.10-0.15 |
| Lube oil capacity (L) | 1.65 |
| Starting motor (V,kW) | 12V 0.8kW |
| Charging generator(V,A) | 12V 3A |
| Battery capacity(V,AH) | Above 12V-36AH |
| Dimension (L*W*H)(mm) | 522*522*578 |
| Net weight(kg) | 47 |
