seven-roller coreless recoiler

Specifications

Seven-roll Coreless Reeling Machines is used for the reeling of hot sheet material or the pickling hot sheet material,

1 Function

Seven-roll Coreless Reeling Machines is used for the reeling of hot sheet material or the pickling hot sheet material

 2 Composition

mainly made up of components like the guiding roll, the locating rack, the archway, the work roll, the bull bars, the synchromesh gear box, the connecter, the reduction box, the motor power, the bearing lubrication system and the electric control system, etc.

  3 Specification

For it has tension structure for auto bend-shaping itself, it doesn’t need the collapsible drum (coreless). It is convenient to hang up the volume material after reeling. The two sides of it have the turning protection rolls that make it wind regularly and be operated safely. The synchronizer gear case can make the seven-roll transmit synchronously at the same time. The precision gear wheel and gear shaft are precisely processed by the boring mill.

...
