Home > Manufacturing & Processing Machinery > Cutting & Fold-bend Machine > Bending Machine > Wholesales Automatic Steel Twist Machine

Wholesales Automatic Steel Twist Machine

Name: Wholesales Automatic Steel Twist Machine
Brand: Better
SKU: 104304367
Availability: InStock

Wholesales Automatic Steel Twist Machine thumbnail-1

Wholesales Automatic Steel Twist Machine photo-1

US$ 5,000 - 200,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Jiangsu, China

Brand Name:

Better

Contact Supplier Request Quote Chat Now

Nantong Better Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Nantong

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Jiangsu, China

Brand Name Better

Model Number W24Y-30

Machine Type Pipe and Tube Bending Machine

Raw Material Sheet / Plate Rolling

Material / Metal Processed Stainless Steel

Power Hydraulic

Automation Automatic

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Wholesales automatic steel twist machine

Product Description

W24Y-30 automatic steel twist machine Performance:

Shafts made of speical steel, hardened and grounded.

Separate and moveable control panel .

Water coolant system to keep hydraulic oil temperate.

Guide rolls are hydraulic moveable up and down to curve different arc.

Ability to curve tubes, angles, H, I, U as well as other type of profiles by different rolls.

W24Y-30 automatic steel twist machine Parameter:

NO	ITEMS		PARAMETER	UNIT
1	Max. bending no		30	cm²
2	Yielding limited		σS=250	mpa
3	Angle steelcul-turn	Max. section	80x8	mm
3	Angle steelcul-turn	Min. tending DIA	1200	mm
4	Angle steel out-turn	Max. section	90x10	mm
4	Angle steel out-turn	Min. tending DIA	1100	mm
5	Channel steel out-turn	Max. section	16	mm
5	Channel steel out-turn	Min. tending DIA	800	mm
6	Channel steel in-turn	Max. section	16	mm
6	Channel steel in-turn	Min. tending DIA	1000	mm
7	Channel steel sidu-turn	Max. section	8	mm
7	Channel steel sidu-turn	Min. tending DIA	1500	mm
8	Flat steel torzonral-turn	Max. section	180x25	mm
8	Flat steel torzonral-turn	Min. tending DIA	800	mm
9	Flat steel sertical-turn	Max. section	62	mm
9	Flat steel sertical-turn	Min. tending DIA	600	mm
10	Round steel bending	Max. section	89x5	mm
10	Round steel bending	Min. tending DIA	900	mm
11	Round tuby bending	Max. section	70x4	mm
11	Round tuby bending	Min. tending DIA	1000	mm
12	Square tute bending	Max. section	−	mm
12	Square tute bending	Min. tending DIA	−	mm
13	Vertical bending beam	Max. section	−	mm
13	Vertical bending beam	Min. tending DIA	−	mm

If you have any other requirements for the size, pls do not hesitate to contact us, or you can advise us your ideas or thoughts for the machine, we can kindly design for you and communicate with you for the details.

Details photos:

Our machines can bend wide range of structural steel section,Flat bars, Solid Square or Round , Angle Iron (Leg In or Out), Round Tube, Square Tube, Rectangular Tubing and so on.

Packaging & Shipping

Our Services

FAQ

1.How about your W24Y-30 automatic steel twist machine quality?

Better is a mature brand in CHINA,through our many years research in technology. our design including structure and detailed security and precision has enhanced greatly,and can match all the CE standard or more strict standard.Our machines distribute worldwide to about 50 countries where there are metal plate industry ,there are Better machines.

2. What’s your after-sale service?

Better provide oriented after-sales service including the oversea engineers training available and also international dealer center for any emergency guidance.We have established worldwide network to guarantee our timely response for your any demand no matter where are you.

We welcome engineers from your side to learn the technical design and normal maintenance here,this will help your easy in understanding and helpful if you need to be our dealer.

3. How to operate your W24Y-30 automatic steel twist machine?

Don’t worry,we have our company own CD/Manual to show you along with the machine.So you can learn this from the existing documents to deepen your knowledge and understanding. Anyhow there are another way is through internet video face to face for machine teaching, because of the high development in internet,the world has become smaller and you can easy catch us if any assistance needed .
