Touch Screen Hot Cold Cycling Equipment Factory Direct Sell
US$ 3,700 - 6,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Harris
Model Number:
TGDW-100TA
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
10 Years Factory Temperature Simulating Benchtops PriceUS$ 3,700 - 6,000MOQ: 1 Set -
Professional Factory Temperature Cycling Test ChamberUS$ 3,700 - 6,000MOQ: 1 Set
-
Professional Manufacturer Criterion Temperature Benchtop ChambersUS$ 3,700 - 6,000MOQ: 1 Set
-
10 Years Factory Temperature Only Benchtop Chamber PriceUS$ 3,700 - 6,000MOQ: 1 Set
-
Factory Price Criterion Temperature BenchtopUS$ 3,700 - 6,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
Harris
Model Number
TGDW-100TA
Power
Electronic
Usage
Other, Environmental test chamber
Touch screen hot cold cycling equipment factory direct sell
Product Description
Hot cold cycling equipment is also known as hot and cold impact testing machine, used to test
or composite material structure, in an instant by the extremely high temperature and low temperature under continuous environment can endure degree, in order to test in the shortest possible time chemical changes caused by heat bilges cold shrink or physical damage. Applicable to metal and plastic, rubber, electronic...Such as material, can be used as the basis of its product improvements or reference.
|
Hot cold cycling equipment | ||||||||||
| Specification | TGDW-100UA | TGDW-150UA | TGDW-250UA | TGDW-500UA | TGDW-010UA | |||||
| Workroom Sizes W*D*H (cm) | 50x40x50 | 50x50x60 | 60x60x70 | 80x70x90 | 100x100x100 | |||||
| Inner chamber volume(V) | 100L | 150L | 252L | 504L | 1000L | |||||
| Outer dimension W*D*H(cm) | 98x95x160 | 98x105x170 | 108x112x180 | 128x125x200 | 148x155x210 | |||||
| Packing Size | 113x110x175 | 113x120x185 | 123x127x195 | 133x140x215 | 163x160x225 | |||||
| G.W(kg) | 340 | 370 | 430 | 460 | 600 | |||||
| Temperature Range | A: -20°C-150°C B: -40°C-150°C C: -60°C-150°C D: -80°C-150°C | |||||||||
| Temperature Fluctuation | ≤±0.5°C(standard)/≤±0.2°C(optional) | |||||||||
| Temperature Evenness | ≤±2°C | |||||||||
| Temperature Deviation | ≤1°C | |||||||||
| Accuracy | 0.1°C(standard)/0.01℃(optional) | |||||||||
| Temperature Rise Speed | 1.0°C~3.0°C/min | |||||||||
| Temperature Down Speed | 0.7°C~1.2°C/min | |||||||||
| Time needed for heating | RT°C~150°C≤30min | |||||||||
| Time needed for cooling | RT°C~-40°C≤60min | |||||||||
| The machine noise | 72 dB(A) | |||||||||
| Load on the largest | 100kg,≤20kg/layer | 150kg,≤26kg/layer | 260kg,≤30kg/layer | 260kg,≤40kg/layer | 300kg,≤60kg/layer | |||||
| Equipment installed power | ~1.95KW | ~2.35KW | ~2.85KW | ~3.5KW | ~4.35KW | |||||
| material | Inner chamber:# SUS 304 stainless steel | The outer wall:A3 carbon steel plate with plastic spray/#SUS304 | ||||||||
| Wind Cycling Way | Centrifugal fan forced air circulation | |||||||||
| Refrigeration Way | Single stage compression refrigeration | |||||||||
| Refrigerater | French Tecumseh | |||||||||
| Refrigerants | R4O4A USA Dupont environmental protection refrigerant | |||||||||
| Condensing Way | Air-cooled or water-cooled | |||||||||
| Heater | Nickel chrome heating wire heater | |||||||||
| Controller | Japan OYO/Korea Temi | |||||||||
| Design criteria | GJB150.3 GJB150.4 GB/T2423.22 GB10589-89 GB11158-89 | |||||||||
| Standard Accessoriesparts | 1 Observe window(double-deck cavity toughened glass),50mm testing hole,PL internal bulbs,partition plate,dry and wet ball gauze,3 fuses,1 power line | |||||||||
