Reliable Quality Electric Air Blowing Drying Oven Price Made in Jiangsu Wuxi
US$ 2,000 - 8,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Harris
Model Number:
TGH-100UA
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
New Technology Plastic Parts Use Simulated Climate Oven Price for SaleUS$ 5,000 - 8,000MOQ: 1 Set -
Cost Effective Hot Sell High Temperature Aging Oven Machine, High Temperature Aging ChamberUS$ 5,000 - 8,000MOQ: 1 Set
-
Touch Screen Controlled Industrial Heating Dewatering Machine PriceUS$ 5,000 - 8,000MOQ: 1 Set
-
Small Intelligent Temperature Accelerated Weathering Tester ManufacturerUS$ 5,000 - 8,000MOQ: 1 Set
-
New Technology Lab High Temperature Electric Test Oven ManufacturerUS$ 5,000 - 8,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
Harris
Model Number
TGH-100UA
Power
Electronic
Usage
Other, Universal Testing Machine, high temperature test
Reliable quality Electric Air Blowing Drying Oven price made in Jiangsu Wuxi
Product Description
Brief introductions:
This electric air blowing drying oven is designed and manufactured accord to the requirements of IEC 60884, IEC60598 and relevant standards. It is use to simulate a high temperature environment to test the ability of material to withstand thermo-mechanical stress. This machine can be wide used in many industries such as Electrical Appliances, Electrical wire accessories, luminaries, motors, connectors, etc.
This machine has the advantages of easy operate, fast heating, high precision, temperature be even and stable.
Parameters of air blowing drying oven:
Electric air blowing drying oven | ||||||||||
| Specification | TGH-100UA | TGH-150UA | TGH-250UA | TGH-500UA | TGH-010UA | |||||
| Workroom Sizes W*D*H (cm) | 50x40x50 | 50x50x60 | 60x60x70 | 80x70x90 | 100x100x100 | |||||
| Inner chamber volume(V) | 100L | 150L | 252L | 504L | 1000L | |||||
| Outer dimension W*D*H(cm) | 98x95x160 | 98x105x170 | 108x112x180 | 128x125x200 | 148x155x210 | |||||
| Packing Size | 113x110x175 | 113x120x185 | 123x127x195 | 133x140x215 | 163x160x225 | |||||
| G.W(kg) | 360 | 390 | 450 | 480 | 620 | |||||
| Temperature Range | RT℃-300℃ | |||||||||
| Temperature Fluctuation | ≤±0.5°C(standard)/≤±0.2°C(optional) | |||||||||
| Temperature Evenness | ≤±2°C | |||||||||
| Temperature Deviation | ≤1°C | |||||||||
| Accuracy | 0.1°C,1.5%R.H (standard)/0.01℃,1.5%R.H(optional) | |||||||||
| Humidity Range | 20%~98%R.H/10%~98%R.H(optional) | |||||||||
| Humidity Deviation | ±2% R.H | |||||||||
| Temperature Rise Speed | 0.5°C~5°C/min(programmable) | |||||||||
| Time needed for heating | RT°C~250°C≤60min | |||||||||
| The machine noise | 72 dB(A) | |||||||||
| Load on the largest | 100kg,≤20kg/layer | 150kg,≤26kg/layer | 260kg,≤30kg/layer | 260kg,≤40kg/layer | 300kg,≤60kg/layer | |||||
| Equipment installed power | ~3.25KW | ~3.55KW | ~3.95KW | ~5.5KW | ~6.25KW | |||||
| material | Inner chamber:# SUS 304 stainless steel | The outer wall:A3 carbon steel plate with plastic spray/#SUS304 | ||||||||
| Wind Cycling Way | Centrifugal fan forced air circulation | |||||||||
| Heater | Nickel chrome heating wire heater | |||||||||
| Humidifier | Semi-closed steam and wet | |||||||||
| Water Suplying Way | Automatic cycling water supply | |||||||||
| Controller | Japan OYO/Korea Temi | |||||||||
| Standard Accessoriesparts | 1 Observe window(double-deck cavity toughened glass),50mm testing hole,PL internal bulbs,partition plate,dry and wet ball gauze,3 fuses,1 power line | |||||||||
