Home > Instruments & Meters > Test Instrument > Test Machine > Good Quality High Temperature Humidity Black Garlic Machine, Black Garlic Equipment
Good Quality High Temperature Humidity Black Garlic Machine, Black Garlic Equipment
US$ 4,200 - 8,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Harris
Model Number:
THS-408L
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
10 Years Factory Black Garlic Processing Equipment WholesaleUS$ 4,000 - 8,000MOQ: 1 Set -
New Technology OEM Black Garlic Aging Equipment PriceUS$ 4,200 - 8,000MOQ: 1 Set
-
High Temperature Humidity Simulating Machines Black Garlic PriceUS$ 3,800 - 5,800MOQ: 1 Set
-
Factory Direct Sell Black Garlic Fermentation Box PriceUS$ 3,800 - 5,800MOQ: 1 Set
-
High Temperature Humidity Black Garlic Climatic Chamber PriceUS$ 3,800 - 5,800MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
Harris
Model Number
THS-408L
Power
Electronic
Usage
Other, black garlic making
Good quality high temperature humidity black garlic machine, black garlic equipment
Product Description
Brief introduction
1.Black garlic machine adopts high temperature and high humidity vertical and horizontal complementary flow design.
2.Can be customized according to customer's requirements.
3.Low noise, smooth operation, automatic temperature control, wide application scope.
4.Equipment operation is simple.
5.Short fermentation period, low power, save electricity and energy saving.
6.With equipment power automatic adjustment function, according to the original curve automatic adjustment function.
| Capacity reference | ||||||||
| Workroom size(mm) | Fresh garlic capacity | Tray size(mm) | Total bulbs | Tray | ||||
| 450x550x755 | 8kg | 380x420 | 252 | 6(42bulbs/tray) | ||||
| 550x550x755 | 10kg | 380x420 | 294 | 7(42bulbs/tray) | ||||
| 750x850x1125 | 15kg | 600x400x48 | 480-560 | 8(60-70bulbs/tray) | ||||
| 750x850x1465 | 25kg | 600x400x48 | 720-840 | 12(60-70bulbs/tray) | ||||
| 1490x850x1635 | 50kg | 600x400x48 | 1440-1680 | 24(60-70bulbs/tray) | ||||
| 1490x1075x1635 | 100kg | 600x400x48 | 2880-3360 | 48(60-70bulbs/tray) | ||||
| Customizable | 200kg | 600x400x48 | 5760-6720 | 96(60-70bulbs/tray) | ||||
| Customizable | 500kg | 600x400x48 | 14400-16800 | 240(60-70bulbs/tray) | ||||
| Customizable | 1000kg | 600x400x48 | 28800-33600 | 480(60-70bulbs/tray) | ||||
| Specification | THS series Black Garlic Machine | |||||||||
| Workroom Sizes W*D*H (cm) | Customized according to customers need | |||||||||
| Temperature Range | 40°C-100°C | |||||||||
| Temperature Fluctuation | ≤±0.5°C(standard)/≤±0.2°C(optional) | |||||||||
| Temperature Evenness | ≤±2°C/≤±5℃ | |||||||||
| Temperature Deviation | ≤1°C | |||||||||
| Accuracy | 0.1°C,1.5%R.H (standard)/0.01℃,1.5%R.H(optional) | |||||||||
| Humidity Range | 50%~98%R.H | |||||||||
| Humidity Deviation | ±2% R.H | |||||||||
| Temperature Rise Speed | 1.0°C~3.0°C/min | |||||||||
| Temperature Down Speed | 0.7°C~1.2°C/min | |||||||||
| Time needed for heating | RT°C~100°C≤30min | |||||||||
| The machine noise | 65 dB(A) | |||||||||
| material | Inner chamber:# SUS 304 stainless steel | The outer wall:A3 carbon steel plate with plastic spray/#SUS304 | ||||||||
| Wind Cycling Way | Centrifugal fan forced air circulation | |||||||||
| Heater | Nickel chrome heating wire heater | |||||||||
| Humidifier | Semi-closed steam and wet | |||||||||
| Water Suplying Way | Automatic cycling water supply | |||||||||
| Controller | Japan OYO/Korea Temi | |||||||||
| Standard Accessorie sparts | 1 Observe window(double-deck cavity toughened glass),50mm testing hole,PL internal bulbs,partition plate,dry and wet ball gauze,3 fuses,1 power line | |||||||||
| Safety device | Fuse protection, Overheat protection,humidifier dry-combustion protection ,over-humidity and temperare protection,water shortage protection,over-current protection,earth leakage protection | |||||||||
