Precision Automatic Leveling Machine of W43
| W43-6X2000 Leveling Machine Performance: |
Automatic plate leveling machine has two pinching rolls at the entrance side of the machine, they can transport the plates.leveler machine a special equipment for mental material working. It is used for straightening curling simplified sheet in cold condition and uneven sheet in cold condition and uneven sheet (mixed with carbon ,stainless plate,aluminums sheet ,other mental plate) It may accord to the relative equipment or opening straightening ,cutting production line and other metal sheet materials producing lines and be suitable for machinery ,vehicles, metal production ,household appliances, steel structure, ornament.
| W43-6X2000 Leveling Machine Specification: |
| Model | 6*2000 |
| Max. levelling thickness (mm) | 6 |
| Max. levelling width (mm) | 2000 |
| Min.levelling thickness (mm) | 1.5 |
| Plate yield limit (mpa) | 360 |
| Distance between work rollers (mm) | 100 |
| Work roller diameter (mm) | 95 |
| Work roller number (mm) | 13 |
| Levelling speed (m/min) | 9 |
| Main motor power (kw) | 37 |
| Overall dimensions(L*W*H) (mm) | 5960*1480*3000 |
If you have any other requirements for the size,please do not hesitate to contact us,or you can advise us your ideas or thoughts for the machine,we can kindly design for you and communicate with you for the details.
1.How about your W43-6X2000 Leveling Machine quality?
Better is a mature brand in CHINA,through our many years research in technology. our design including structure and detailed security and precision has enhanced greatly,and can match all the CE standard or more strict standard.Our machines distribute worldwide to about 50 countries where there are metal plate industry ,there are Better machines.
2. What’s your after-sale service?
Better provide oriented after-sales service including the oversea engineers training available and also international dealer center for any emergency guidance.We have established worldwide network to guarantee our timely response for your any demand no matter where are you.
We welcome engineers from your side to learn the technical design and normal maintenance here,this will help your easy in understanding and helpful if you need to be our dealer.
3. How to operate your W43-6X2000 Leveling Machine ?
Don’t worry,we have our company own CD/Manual to show you along with the machine.So you can learn this from the existing documents to deepen your knowledge and understanding. Anyhow there are another way is through internet video face to face for machine teaching, because of the high development in internet,the world has become smaller and you can easy catch us if any assistance needed .
