Home > Metallurgy, Mineral & Energy > Solar & Renewable Energy > Solar Cell > Mono Cell 100W EFTE Type Semi Flexible Solar Panel
Mono Cell 100W EFTE Type Semi Flexible Solar Panel
US$ 1 - 1.6
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
CREATOP
Model Number:
CTMS-100
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI/NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sale 20% High Efficiency Flexible Solar Panel, Mono Semi Flexible Solar Panel, 100 Watt Flexible Solar Panel China Quality ChoiceUS$ 0.8 - 1.2MOQ: 1 Piece -
HOT SALE Solar Panel Manufacturers in China,20% Efficiency 100 Watt Semi Flexible Solar Panel Quality ChoiceUS$ 0.8 - 2MOQ: 1 Piece
-
20% High Efficiency 50W Mono Semi Flexible Solar Panel Quality ChoiceUS$ 0.8 - 2MOQ: 1 Piece
-
100W Monocrystalline Semi Flexible Solar PanelUS$ 1 - 2MOQ: 50 Pieces
-
Hot Sale 33W SOLAR KIT FLEXIBLE ROLLED PanelUS$ 3 - 4MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
CREATOP
Model Number
CTMS-100
Material
Monocrystalline Silicon
Size
1060x540x3mm
Number of Cells
32
Max. Power
100
mono cell 100W EFTE type semi flexible solar panel
Product Description
Our flexible 100W sunpower solar panel uses advanced technology backed by Sunpower Monocrystalline solar cells that have been laminated into a flexible plastic sheet.
The result is a solar panel that is far more durable than traditional glass and aluminum models, with twice efficiency (approx. 20%) of flexible thin film solar panels.
With these advanced solar cells, you will get greater power efficiency even though the bendable panel is no larger than a traditional model.
The plastic back sheet can be curved to a maximum 30 degree arc and mounted on an RV, boat, cabin, tent, or any other irregular surface.
The flexibility of this bendable panel also makes it ideal for storage in tight spaces or crowded areas that are typically off limits for traditional glass and aluminum models.
While this Bendable solar panel packs 100W of power, it only weighs a mere 2.0KGS, making it easier to transport, hang, and remove.
The laminate coating on the exterior of the panel makes it impervious to saltwater splashing, rain, and other weather elements.
While this panel may be damaged by sharp objects or scraping, there is no risk of shattering or cracking.
| CTMS-100 | ||||
| Cells | Mechanical Data | |||
| Cell Technology | Monocrystalline | Dimension of solar module | 1060x540x3mm | |
| Number of cells per module | 32pcs | Weight | 2.0KGS | |
| Cell Type | Sunpower mono | |||
| Electrical Data | ||||
| CTMS-100 | ||||
| Maximum power | 100W | |||
| Open circuit voltage (V): | 21.7V | |||
| Max. power voltage (V): | 17.7V | |||
| Short circuit current (A) | 6.10A | |||
| Max. power current (A): | 5.70 A | |||
| * At Standard Test Conditions(STC) Irradiance 1000Watt/m2, AM1.5 100mW/cm2 25’C | ||||
| Thermal Data | ||||
| Temperature coefficients of Voc (%) | -0.38/ ℃ | |||
| Temperature coefficients of Isc (%) | +0.1/ ℃ | |||
| Temperature coefficients of Pm (%) | -0.47/ ℃ | |||
| Temperature coefficients of Im (%) | +0.1/ ℃ | |||
| Temperature coefficients of Vm (%) | -0.38/ ℃ | |||
| Temperature Range | -40℃~+80℃ | |||
| Warranty | ||||
| 2 years Full warranty on the Material and workmanship, and a performance warranty of 90% of the minimal rated power output (Pmpp 0 to +3%) during the first ten (10) years and 80% during twenty-five (25) years | ||||
Our Services
Company Information
FAQ
We have amorphous silicon thin-film flexible solar panels and semi flexible mono/poly solar panels for car, boat, roof and others using.
Customised order is welcome.
Please feel free to contact us for further details.
