Compression Tension Prices of s Type Load Cell

Name: Compression Tension Prices of s Type Load Cell
Brand: GXSENSOR Support OEM
SKU: 104238385
Availability: InStock

US$ 69 - 100 MOQ: 1 Piece

Key Specifications

Place of Origin:

Shaanxi, China

Brand Name:

GXSENSOR Support OEM

Model Number:

LC-S8

Xi'an Kacise Optronics Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or other

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shaanxi, China

Brand Name GXSENSOR Support OEM

Model Number LC-S8

Usage Other, Pressure sensor

Theory Other, Resistance sensor

Output Analog Sensor

Compression tension prices of s type load cell

Features

Features of s type load cell

Tension or compression
High accuracy, reliability, and stability
Compatible, installing easily, and good interchangeability
Optional measurement range: 0.2kN- 100kN (approximate 20kg-10t)
Applying to crane scale, batcher scale, packing scale, electro-mechanic scale and so on

Parameter of compression load cell

Technical Data
Material	Alloy Steel or Stainless Steel
Rated Load	0.2/0.3/1/2/3/5/10/20/30/50/75/100kN
Performance
Overall Precision	0.02(linearity + hysteresis + repeatability)
Sensitivity	2.0mV/V
Excitation voltage	5~12V DC Recommend 10V DC
Creep(in 30 min)	±0.03%F.S/30min
Zero Balance	±1.0%FS
Input Resistance	400±20Ω
Output Resistance	352±3Ω
Insulation	≥5000MΩ
Working Environment
Safety overload	150%F.S
Ultimate overload	200%F.S
Operation temperature	-30~+70°C
Zero Drift	±0.02%F.S/10°C
Output Drift	±0.02%F.S/10°C
Protection Class	IP65

Dimension of prices of load cell

Rated Load(kN) Dimension(Unit: mm, Error: ±1mm)
	A	B	C	R	D
0.2~1.5	64	70	12	74	M8×1.25
2~5	64	70	20	74	M12×1.75
7~10	64	70	25	74	M12×1.75
12~50	90	90	32	94	M20×2
75	90	90	40	94	M24×2
100	110	110	50	94	M30×2
