Help CenterPrice Computing Scales 50kg 100kg Load Cell Sensor
Related Products
-
Platform Scale Electronic Weight Sensor for TrucksUS$ 165 - 851MOQ: 1 Piece -
5t Cost-effective Weight Sensors for Truck ScalesUS$ 70 - 500MOQ: 1 Piece
-
300kg Platfrom Scales Electronical Scale Vehicle Weight SensorUS$ 140 - 175MOQ: 1 Piece
-
300kg Platform Scale Weight SensorUS$ 80 - 300MOQ: 1 Piece
-
100kg Weight Sensors PriceUS$ 130 - 230MOQ: 1 Piece
price computing scales 50kg 100kg load cell sensor
Features of load cell
- Easy to install
- Range: 0-50kg, 0~100kg
- Good corrosion resistance and long-term stability
- Applied to test and control of compression or tension
- Built-in high accuracy transmitter; direct output of standard current and voltage, digital signal (0-20mA)
Parameter of 50kg load cell
Description | |
Material |
Aluminum Alloy |
Rated Load(kg) |
50kg,100kg |
Performance | |
Overall Precision |
0.1(linearity + hysteresis + repeatability) |
Output Signal |
0~20mA |
Excitation voltage |
24V DC |
Zero balance |
±1.0%FS |
Working Environment | |
Safety overload |
120%F.S |
Ultimate overload |
150%F.S |
Operation overload |
-20~+60°C |
Zero Drift |
±0.3%F.S/10°C |
Protection Class |
IP65 |
Products of 100kg load cell
Our Services
Sensor can be customized by your special request, We can supply technical consulting service for your user.
The quality principle: Quality is the best sales
Payment: We accept T/T, PayPal, Western Union, MoneyGram , Escrow
Shipping:
1. All parts will be shipped out within 1 - 3 working days after confirm the payment
2. DHL / FEDEX / UPS / EMS / TNT / China Post /Aramex
3. We are not responsible for force majeure accidents, delays or other issues, like the shipping service.
After-sales service
We can offer good technical support and good warranty for you after service as professional manufacturer.
Warranty: One year
During the warranty, if the goods after delivery are damaged with error caused only by itself quality problem, the goods can be returned for free repair and maintenance. however, if the goods is damaged with error caused by user’ s man-made and force majeure factor, we will be not responsible for free repair and maintenance.
GUANGXING pressure, level and flow Instruments has been certified with ISO 9001 (2008)achieved GB/T19001-2008/ISQ9001:2008, GJB 9001B-2009, CE and RoHS, intrinsic safety explosion-proof and isolated safety explosion-proof certification. we developed a lot of sensor products, such as a pressure sensor / transducer / sensor, level transmitter / ultrasonic level meter / ultrasonic flow meter, etc. Our products are widely applied in the fields of chemical industry, petroleum, pharmacy, electricity, municipal works, environmental protection, food and paper-making.
We have the key technology and development center of advanced sensors, and we cooperation with Northwestern Polytechnical University, Xi'an Jiao Tong University and other colleges and universities. Product quality is the life of enterprise, customer demand is our existence!
