50kg 20t Cantilever Beam Parallel Load Cell

Name: 50kg 20t Cantilever Beam Parallel Load Cell
Brand: GXSENSOR Support OEM
SKU: 104237929

US$ 75 - 160 MOQ: 1 Piece

Key Specifications

Place of Origin:

Shaanxi, China

Brand Name:

GXSENSOR Support OEM

Model Number:

LC-L2

Xi'an Kacise Optronics Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai or other

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shaanxi, China

Brand Name GXSENSOR Support OEM

Model Number LC-L2

Usage Pressure Sensor

Theory Resistance Sensor

Output Analog Sensor

50kg 20t cantilever beam parallel load cell

Features

Features of cantilever load cell

Wide measurement range and stable performance
Low altitude, easy to install and strong versatility
Applied in truck scale, electronic scale, hopper scale etc
Optional measurement range: 0.5-200kN (approximate 50kg-20t)
Selection of accessories about indenter or supporting feet and easy matching

Parameter of beam load cell

Description
Material	Alloy Steel or Stainless Steel
Rated Load(kg)	0.5/1/2/3/5/10/20/30/50/100/150/200kg
Performance
Overall Precision	0.03(linearity + hysteresis + repeatability)
Sensitivity	2.0mV/V
Excitation voltage	5~12V DC (Recommend 10V)
Creep(30 min)	±0.02%F.S/30min
Zero balance	±1.0%FS
Input Resistance	380±10Ω
Output Resistance	350±3Ω
Insulation Resistance	≥5000MΩ
Working Environment
Safety overload	150%F.S
Working Temperature	-20~65°C
Zero Drift	±0.02%F.S/10°C
Output Drift	±0.02%F.S/10°C
Protection Class	IP67
