TAIYITO Demotic Kit ZigBee Home Automation KNX Home Automation Products
kit zigbee home automation
protocol open
factory price
accept OEM/ODM
MOQ:1set
Now Our ZigBEE home automation system can realize control light,electric appliance(like water heater,DVD,TV,AC,background music etc.),electric curtain,windows,door lock,fresh air machine,electric clothes airer, home secutiry alarm system and home automation system etc...and to check the working status by smartphone/Ipad in home orby far.
1.Product specificatons of home automation system
| product type | home automation system |
| work voltage | 80VAC--240VAC |
| Max. Current | 20A of home automation system |
2.Product features of smart home automation system
| home automation system | receiving signals wireless ZigBEE 2.4G control signals of home automation system |
| Colorful design, full of science and fashion of home automation system | |
| Front Panel: 86x86x13mm; Back Panel: 52x49x26mm of home automation system |
duct details of home automation system
Name |
home automation system |
Zigbee Protocol |
IEEE 802.15.4 |
Appliances |
1. lighting/lamp system(ON/OFF and dimming) 2. household electric apparatus(TV,AC,DVD,water heater,fans,ETC 3. window, electric curtain(Open/Close/Stop) 4. door lock(Open/Close) 5. AV, background music(ON/OFF/Channel/Volumn...) 6. home alarm system and other security products 7. home monitor system |
Function control |
1.IOS/ Android smart phone Apps control ephone long distance control 3.Scene control; 4.wall centralized control; 5.remote control& Timing control |
|
Controlled products (receive commands) |
all kinds of switches or TDWZ6436 or TDZ4202S |
|
Controller products (send sommands) |
TDWZ6617 with apps |
Installation |
Steps Step1: wire connection Step2: networking Step3: setting gateway and apps Step4: setting address code |
4:Why choose wireless zigbee smart home automation system but not others
Zigbee protocol is based on the IEEE802.15.4, is a standard low-power networking protocol. According to the international standards,zigbee is a short-distance, low-power wireless communications technology and R&D in 2001 and has 12 years history. The characteristic are short-distance,low Complexity,self-organization, low-power, low data rate, low products cost, bidirectional communications, and high security, is very suitable for smart home system
|
RF RF: has a poor anti-jamming capability, inconvenient network, common ratability, easy string network and have a bad effect in smart home. |
Z-Wave Z-wave: fewer nodes and a limited accommodation; stump web structure is not stable, and have poor security, easy to be vulnerable. The 9.6kps transmission rate is too small to meet the actual needs of the smart home. In our country, the Z-wave frequency bands are mainly used for non-civilian is been limited in policy. And it is difficult to meet in home. |
|
Bluetooth Bluetooth: the communication distance is too short (within 10m), is the point to point communication ways, so Bluetooth products will provide some personalized experience. According to smart home requirements, it is not so suitable. |
Wi-Fi Wi-Fi: is a short-haul transmission technology, has low products cost, and are very common in our life, But in smart home, it has obvious drawbacks, high power and networking needs strong professional. High-power is a fatal drawback for anywhere installing the low-power products. And another fatal drawback is casually to buy a web card can easily break the Wi-Fi account and password. |
5.The following is an demo list for one set TAIYITO bidirectional home automation system
| One Set of Zigbee Home Automation | |||
| Model No. | Description | Quantity | Function |
| PCS | |||
| Touch central control---wall type (timing fucntion) | |||
| TDWZ6406 | Zigbee Touch Screen Wall Mount Centralized Controller | 1 | Centralized Control |
| Central controller with free ios/android apps (Mainframe - Necessary in the system) | |||
| TDWZ6617 | Zigbee Network Service Controller(Including free ios&android apps) | 1 | Gateway/Mainframe |
| Scene control | |||
| TDWZ6402M | Zigbee Touch Screen 2-way Scene Switch(Max 16 addresses per scene) |
1 | Scene controller |
| Lighting Control(1/2/3 gang switch& 1 gang dimmer) | |||
| TDZ4401M | Zigbee Touch Screen Dimmer Switch | 1 | One gang touch screen dimmer, for dimmer control(≤300W) |
| TDZ4203M | Zigbee Touch Screen Fluorescent Lamp/Appliance Switch(Max1500W) | 1 | One-gang light switch, for lighting control(≤1500W) |
| TDZ4404M | Zigbee Touch Screen 2-way Fluorescent Lamp/Appliance Switch | 1 | 2-gang light switch, for lighting control (≤300W per gang) |
| TDZ4405M | Zigbee Touch Screen 3-way Fluorescent Lamp/Appliance Switch | 1 | 3-gang light switch |
| Smart Socket Control (Water heater)---Receivers( receive commands) | |||
| TDZ4202S | Zigbee Smart Socket | 1 | On/off appliances(such as Water heater), socket/outlet |
| IR Devices Control (TV , DVD , Home cinma , air condition with IR receiver) | |||
| TDWZ6436 | Zigbee IR Transceiver | 1 | Infrard devices receivers, 360° angle, copy 32 IR codes, so one TDWZ6436 can control several IR devices in one room(no shelter between IR devices and TDWZ6436) |
| Electric Curtain Control | |||
| TDZ4470M | Zigbee one way Touch Screen Automatic Curtain Switch for TDX4470 | 1 | Curtain touch switch |
| TDX4470 | Flat-open Electric&manual Curtain Motor with assistance | 1 | Curtain motor(can pull by hand) |
| TDX4470G | N0-adjustment Flat-open Electric&manual Curtain Track(60W) | 2 meter | Curtain track(work with TDX4467) |
| Door Lock Control | |||
| TDZ4488M | Zigbee Touch Screen Fingerprint door lock Switch | 1 | Door lock Switch(work with our door lock only) |
| TDXZ116 | Fingerprint Door Lock (with dustproof shield) | 1 | Indoor lock |
| Fan | |||
| TDZ4485M | Zigbee Touch Screen Fresh Air Switch with three gear | 1 | Fan with 3 speeds |
| background music system | |||
| TDXBM206 | AV Multimedia controller(485 port) | 1 | RS485 port |
| TDXBM404 | Ceiling Speaker | 4 | It work with TDXBM206 |
| TDWZ485-HS—background music | zigbee-RS485 interface background music | 1 | It applies to Zigbee system.Bidirectional communication.Use APP to control background music products in home automation system |
| IP Camera Control | |||
| TDX6618H | Network Camera(1 M Pixels) | 1 | Indoor Camera |
| TDX6618W | Network Camera(Outdoor,Mega Pixels) | 1 | Outdoor Camera |
| Security System | |||
| TDSK239K | Security Mainframe work with apps software | 1 | Security Mainframe |
| TDSK160L | Wireless Pasive Intelligent IR Detetcor | 1 | Wireless Detector |
| TDWZ485 | Interface about zigbee to RS485 | 1 | zigbee to RS485 Interface between TDWZ6617 and TDSK239K |
| TDSK-03WD | Wireless Door Magnetism Sensor | 1 | Wireless door or window sensor |
| TDSK-239GSM | GSM alarm module work for Mainframe | 1 | It has GSM function work with TDSK239K,so that you only plug into SIM card then you can do alarm. |
| TDSS-168 | Wireless Smoke Detector | 1 | |
| Roller Control | |||
| TDZ4466M | Zigbee one way Touch Screen Automatic Curtain Switch | 1 | Curtain touch switch |
| TDX4468 | Roller blind electric curtain Motor(10N) | 1 | Roller blind |
| TDX4468G | Roller blind Electric Curtain Track(φ50) | 1meter | Roller track(work with TDX4469) |
| Intelligent video intercom system | |||
| TDX0900M-DNK | Video intercom indoor panel(wired) | 1 | Indoor Panel |
| TDX0900D-DNK | Video intercom outdoor panel(without card) | 1 | Outdoor Panel |
| TDX0900P-DNK | Power supply for Video intercom | 1 | 1pc power supply can load Max 2pc indoor panel and 1pc outdoor panel |
| TDWZ485-DK—Video Intercom | zigbee-RS485 inteface visual intercom | 1 | It applies to Zigbee system.Bidirectional communication.Use APP to control visual intercom in home automation system |
| HAVC Control (If your Central Air-Condition is without IR receiver) | |||
| TDWZ485 | Interface about zigbee to RS485 | 1 | Interface between zigbee system and thermostat |
| TDXYLA | Central air-condition thermostat | 1 | thermostat with RS485 interface |
| gas valve control function:when it detect gas leak ,the mechanical arm will be closed | |||
| TDX6842 | Combustible Gas Detector | ||
| TDZ4462M | Zigbee Touch Screen mechanical arm Switch | It applies to Zigbee system.Bidirectional communication.Work together with TDX6840 | |
| TDX6840 | Mechanical arm | ||
5.How to install the TAIYITO bidirectional home automation system
We take video about install ,and upload to Youtobe.pls check the following Youtobe web link
/playlist?list=PLf91VzoPNao99PJ918l3UiXAkIXXT3IiQ
We are the IEEE802.15.4 Wireless Zigbee home automation R&D manufactory .We are specialize in home automation around 11 years.
With our domotic zigbee home automation ,you can control almost all electric devices(like light,dimmer light,TV,AC, water heater,electric curtain,door lock,window,security prouduct,IP camera,AV system etc...) in house using (iphone or android )mobile/Ipad /wechat/smart TV
1.Certificate about TAIYITO bidirectional home automation system
2.TAIYITO bidirectional zigbee home automation system in fair
1.What kind of Payment that TAIYITO bidirectional zigbee home automaton system can accept?
2.How do you provide after sale service home automation system ?
About technical problems resolution------After becoming agents or distributors, we will give your technical team training, they will be responsible for solving your clients' technical problems, if you have any questions, you can contact with our techologists at any time.
1.How to Delivery TAIYITO bidirectional zigbee home automation system to your hand?
2.How to pack the TAIYITO bidirectional home automation system to your hand?
| Question | Answer |
| How about your zigbee home automation system performance? Are they stable? | Our company began to do home automation from 2003 year and mainly export to Western Europe, North Europe, Australia, these countries have more strict request on quality. So you can see that our products are stable. |
How to find us if you want to buy home automation system products ?
