PVC plate vulcanizer/vulcanization machine/rubber machine
- 0 per Month
- Qingdao
- T/T
Product Details
Condition: | New | Type: | Vulcanizer | Place of Origin: | Shandong, China |
Brand Name: | BOJIA | Voltage: | 380V | Certification: | ISO |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
PVC plate vulcanizer/vulcanization machine/rubber machine
Structure & Features
This vulcanizing machine has perfect function and compact structure. Time lock mold, automatic pressure compensate, automatic temperature control, automatic time, and alarm when time reaches. The temperature of plate surface is even and accurate. The temperature controller can record the temperature date accurately and the pressure is stable and reliable.
Main technical Parameters
type | 160T | 100T | 50T | 315T | 250T | 200T |
Normal clamping mould force | 1600KN | 1000KN | 500KN | 3150 | 2500 | 2000 |
Max Working hydraulic pressure(kn) | 16 | 16 | 16 | 16 | 16 | 16 |
hot plate size(mm) | 850*850 | 600*600 | 500*500 | 1200*1200 | 1100*1100 | 1000*1000 |
hot plate space(mm) | 125 | 125 | 125 | 150 | 150 | 150 |
working layers | 4 | 2or4 | 2or4 | 2 | 2 | 4 |
max plunger stroke(mm) | 500 | 500 | 500 | 350 | 350 | 600 |
heating mode | steam/electric | steam/electric | steam/electric | steam/electric heating | steam/electric heating | steam/electric heating |
hot plate pressure per unit area(KN) | 2.5 | 2.8 | 3.12 | 2.2 | 2.1 | 2 |
motor power(kw) | 3 | 3 | 2.2 | 7.5 | 5.5 | 4 |
dimension(mm) | 3000*1600*2523 | 2070*1050*2230 | 1470*640**400 | 1685*1320*2550 | 1780*1150*2434 | 1800*1200*2650 |
weight(kg) | 6811 | 1900 | 1300 | 9500 | 8300 | 7900 |
note | column | column | column | plate frame | plate frame | plate frame |
Qingdao Bojia Machinery Manufacturing Co., Ltd changed officially its name from a state-owned machinery company in October 2007, is one professional machinery manufacturer. Our company have one good and high quality design and manufacturing technology development group, often communicate with the customers and technology authority departments of rubber industry, constantly to improve and update our products which can meet the requirements of the customers; Our company guarantee to provide you excellent pre-market sale and after-sale service, timely technology information consulting, accessories and consumable parts supply etc, also can design and manufacture various non-standard products according to users’ requirements.
Our main products are: Conveying Belt Molding Machine Series; Batch Off Cooling Machine Series; Cushion Cloth Renovating Machine Series; Open Mixing Mill Series; Vulcanizing Press Series; Rubber Cutting Machine Series; Rubber Slitting Machine Series; Longitudinal Cutting Machine Series; Conveyer Belt Machine Series; Other Rubber Machines; Design and Manufacturing of Automatic Production Line.
Bojia Machinery Company always pursue "quality first, customer first" principle to offer high-quality products and excellent service, welcome new and old customers to visit my company.
Package: internal: stretch protection film
external: standard export wooden package
delivery: 30 days after receiving the deposit
