Hydraulic Double-mold Rubber Tyre Vulcanizing Press
l Usage
The hydraulic press/conveyor belt vulcanizer/plate vulcanizing press is used to vulcanize common rubber conveyor belt, nylon conveyor belt, PVG conveyor belt, steel wire core conveyor belt fabric core parallel adhesive tape.
l About the machine
1.PLC is used in the control system of mainframe that can meet multi-program automatic control,and platen temperature can be measured and adjusted automatically during the course of curing.
2.This machine is equipped with high and low pressure oil pumps directly driven by the motor.
3.The motor is started by magnetic starter. The thermal relay installed inside is used as overload protector. When the motor is overloaded or in fault, the machine will stop automatically.
l Main technical parameters
|
Model Item |
XLB-DQ 350*350 |
XLB-DQ 400*400 |
XLB-Q 600*600 |
XLB-Q 1400*3200 |
XLB-Q 1500*6000 |
XLB-G 1800*10000 |
XLB-G 2400*12000 |
|||||
Total pressure |
KN |
250 |
500 |
1000 |
10300 |
25200 |
72MN |
115-2MN |
||||
Hot-plate unit pressure |
Mpa |
2.1 |
3.1 |
2.7 |
2.3 |
2.8 |
4 |
4 |
||||
Max plunger stroke |
mm |
250 |
300 |
300 |
250 |
250 |
360 |
360 |
||||
|
Hot-plate size |
mm |
350*350 |
400*400 |
600*600 |
1400*3200 |
1500*6000 |
1800*10000 |
2400*12000 |
||||
Plate space |
mm |
75 |
125-150 |
125-150 |
300 |
300 |
360 |
360 |
||||
Plate layers |
|
2-4 |
2-4 |
2-4 |
1 |
1 |
1 |
1 |
||||
Max working-oil pressure |
Mpa |
12 |
12 |
16 |
14.5 |
15.5 |
17.5 |
25 |
||||
Total heating power |
KW |
12 |
12 |
20 |
_ |
_ |
_ |
_ |
||||
Max steam pressure |
Mpa |
0.8 |
0.8 |
0.8 |
0.8 |
0.8 |
1 |
1 |
||||
Overall dimensions |
L |
mm |
1260 |
1260 |
1350 |
3400 |
6400 |
10500 |
12600 |
|||
W |
mm |
560 |
560 |
750 |
2360 |
2520 |
3200 |
4000 |
||||
H |
mm |
1650 |
2200 |
1800 |
3050 |
3420 |
4670 |
5260 |
||||
About weight |
t |
~2 |
~2.2 |
~3 |
~27 |
~60 |
~240 |
~340 |
||||
Our main products are various type of Batch-off cooler , Banbury mixer, Mixing mill ,vulcanizing machine,rubber cutter and other kinds of rubber machinery.We can also make all kinds of non-standard rubber machines according to your requirements.
1. One year warranty and factory price
2. 24 hours technical support
3. Provide all English Software and Manual
4. Provide Door to door service
l show picture
1.Q: Are you a factory or trading company?
A:We are a factory and manufacturer.
2.Q: Where is your factory located? How can I visit there?
A:Our factory is located in Huangdao,Qingdao, China. You can fly to Qingdao Liuting airport directly. All customers are warmly welcome to visit our factory!
3.Q:How does your factory do regarding quality control?
A:"Quality is priority. BOJIA people always attach great importance to quality controlling f
