Hot vulcanizing machine
Usage
Vulcanizing machine is suitable for a variety of vulcanized rubber products, a variety of advanced thermoset compression molding pressing equipment. Vulcanizing machine has two heating steam electric type, mainly by the host, hydraulic system, electric control system has three major components, the fuel tank installed in the host left alone, free from the influence of temperature hot plate; operated valve installed on the host on the left, the workers easy operation, visual spacious. Vulcanizing separate electrical control box mounted on the right side of the host. Electric hot plate at each type has 6 heating pipes, the total power of 2.4KW, 6 pcsheating tube is not equally spaced, each section of each heater power range, which can ensure uniform temperature hot plate, hot plate temperature automatic control, high precision temperature control, processing products of good quality. Can not afford to pressure, no leakage, low noise, precision - high operational flexibility.
Structure Features
1. Two kinds of heating method:steam and electric
2. Three major components:the host ,the hydraulic system and electric control system
3. Hot plate temperature uniformity and automatic control
4. High-precision temperature control makes good-quality products
5. Pessure doen't drop,no leakage,low noise,high precision and flexible operation
We can design various size vulcanizing press, only please inform your detailed requirement, such as total pressure, plate size, working layers, working stroke etc.
Technical Parameters
Model |
200T |
Nominal clamping force |
2000KN |
Max. working liquid pressure |
16 |
Hot plate specification |
900*900 |
Hot plate spacing |
200 |
Working layer number |
2 |
Plunger stroke |
400 |
Heating method |
Steam heating/electric heating |
Unit area pressure of hot plate |
2.5 |
Motor power |
4 |
Overall dimensions |
3000*1000*2300 |
Weight |
4750 |
Note |
Plate-type |
Picture show
1)inside is covered with film before we put them into the plywood ctns, which has good transparency,impact resistance,tasteless and prevent moisture corrosion.
2)outside is strong plywood ctns and accord with export standards.
3)we can ship testing equipments according to customer request.
1. One year warranty and factory price
2. 24 hours technical support
3. Provide all English Software and Manual
4. Provide Door to door service
We can design various size vulcanizing press, only please inform your detailed requirement, such as total pressure, plate size, working layers, working stroke etc.
Qingdao Bojia,Our main products are various type of Rubber sheet cooling machine(Batch-off cooler ),Rubber mixing mill, Cushion cloth renovating machine, DCS - automatic belt billet forming machine, Banbury mixer ,Plate vulcanizing machine, Rubber cutter, Tire retreading production line, Waste tire for rubber power production line and other kinds of rubber machinery. We can also make all kinds of non-standard rubber machines according to your requirement.
1.Q: Are you a factory or trading company?
A:We are a factory and manufacturer.
2.Q: Where is your factory located? How can I visit there?
A:Our factory is located in Huangdao,Qingdao, China. You can fly to Qingdao Liuting airport directly. All customers are warmly welcome to visit our factory!
3.Q:How does your factory do regarding quality control?
A:"Quality is priority. BOJIA people always attach great importance to quality controlling from the beginning to end.
