GX-QJJ-50/60 Single-axis Inclinometer

FOB Price

US$ 2,580 - 4,678 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

GX-QJJ-50/60 single-axis inclinometer

1. Feature

1. single-axis inclinometer
2.high accuracy,wide measurement range
3.temp complement

2. Applications

1).platform control

2). mechanical device

3. Specifications

Model	GX-QJJ-50	GX-QJJ-60
Electrical characteristics
Input voltage(VDC)	10~30 VDC	10~30 VDC
Input current (mA)	≤40mA	≤50mA
Output format	RS-485	4~20mA
Baud rate	19200bps	-
Data update	25Hz	-
Performance Index
Measurement range	±180°
Bandwidth(Hz)	5 Hz
Resolution(%)	0.01°
Non-linear(%)	0.1%FS
Zero offset( 25°C )	0.1°	12±0.1(mA)
Zero offset temp drift	0.1°
Start time(ms)	<1s
Environment characteristics
Working temperature ( c)	-40°C~+70 ^. C
Storage temp. ( )	-40°C~+125 ^. C
Physical Characteristics
Weight (g)	<250g
Size(mm)	60×60×30 mm

******************************************************************************************************************************************

more details ,please contact us.
