Rubber sheet cutting Machine / Tyre strips cutter
l Usage
Cutting large rubber sheets into narrow pcs for using of next process.
l Summary
Rubber slitting machine mainly composed of front and back conveyor belt device, up and down cutting knife device and transmission device etc. Rubber transferred by the front conveyor belt into cutting knife device, and cutting rubber received and transferred by back conveyor belt to material containing box for next process.
l Main technical parameters
1. Maximum width of rubber:800mm;
2. Maximum cutting rubber strips:8 stripS(18 pieces of knife, up and down knife);
3. Minimum width of rubber slice: 100 mm; Maximum width of rubber slice: 190 mm
4. Cutting speed: 15 m/min; (frequency and speed control)
5. Maximum cutting thickness 14 mm;
6. Manual adjustment of leading screw to control up and down cutter location; Adjusting the cutter distance to adjust width of cutting strip; The wear blade can be reusing after repairing by grinding machine.
7. The machine adopts special cutting technology which can assure rubber cutting integrity and no adhesion
8. Front and back adopting no jointing circular conveyor belt to transmit rubber with guiding bar for prevention of running deviation.
9. Height of Conveying bed body: 800 mm.
10. Weight: About 550KGS
11. Dimensions: 2800*1200*1200mm
l About us
Our main products are:Conveying belt molding machine series:Batch off cooling machine series:Cushion cloth renovating machine series:open mixing mill series:Vulcanizing press series:Rubber cutting machine series:Rubber slitting machine series:Logitudinal cutting machine series:Conveyor belt machine series:Other rubber machines:Design and manufacturing of automatic production line.
Bojia machinery company always pursue“quality first,customer first”principle to offer high-quality products and excellent service,welcome new and old customers to visit our company.
l Picture show
* Within 30days after receiving the deposit
* Standard Export Wooden Packing Container
1. The guarantee period is one year. Any quality problem,our company will maintain it free of charge
2. 24 hours email technical support
3. Door-to-Door service
4. Any certification can provide
Qingdao Bojia Machinery Manufacturing Co.,Ltd changed officially its name from a state-owned machinery company in October 2007,is one professional machinery manufacturer.Our company have one good and high quality design and manufacturing technology development group,often communicate with the customers and technology authority departments of rubber industry,constantly to improve and update our products which can meet the requirements of customers:Our company guarantee to provide you excellent pre-market sale and after sale service,timely technology information consulting,accessories and consumable parts supply etc,also can design and manufacture various non-standard products according to users requirements.
Our main products are:Conveying belt molding machine series:Batch off cooling machine series:Cushion cloth renovating machine series:open mixing mill series:Vulcanizing press series:Rubber cutting machine series:Rubber slitting machine series:Logitudinal cutting machine series:Conveyor belt machine series:Other rubber machines:Design and manufacturing of automatic production line.
Bojia machinery company always pursue”quality first,customer first”principle to offer high-quality products and excellent service,welcome new and old customers to visit our company.
