1.Pictures of Waste-heat Regeneration Compressed Air Dryer
3.Chat Flow of Waste-heat Regeneration Compressed Air Dryer
4. Principle of operation of
Waste-heat Regeneration Compressed Air Dryer
ADO is a new type adsorption dryer.It is neither belong to heat regenerative type ,nor heatless regenerative type.It is belong to temperature swing adsorption.
It is using heat energy of the high temperature exhaust from the air compressor to heat the regenerative desiccant and make the adsorbent regeneration.
So ADO can use itself 's resource and make the energy saved.
ADO is 2 towers structure.
The 2 towers are full filled with adsorbent.When one is used to drying,another is used for desorption.
ADO consist 2 alternate using adsorption tower, one set of muffler, one set of air cooler,one set of vapor-liquid separator,one set of switching valve,one set of control system and air source treatment system,optional auxiliary heating system.,etc
5.Technical characteristics of
Waste-heat Regeneration Compressed Air Dryer
1.Using the advanced microcomputer control, communication and joint control, excellence performance
2.Using high quality butterfly valve,fast changing-over, action accurate and reliable
3.Using the gas diffution device, uniform distribution of gas, unique way of filling,long-life time of adsorbent
3.Low regeneration energy consumption
4.Reasonable overall layout, compact structure,easy to install, convenient to use and maitain
6.Technical data of
Waste-heat Regeneration Compressed Air Dryer
Air capacity:10~600Nm3/min
Regeneration air consumption:2%~3%
Work cycle:8h
End air dew point: -40ºC
Cooling water pressure:0.2-0.4MPa
Cooling water temperature:32ºC
Input air temperature:110ºC~220ºC
Work pressure:0.5~1.6Mpa
