TDXE6626+ X10 Intelligent Telephone Control

paper box

Specifications

TDXE6626+  X10 Intelligent Telephone Control

Features:

•   Bidirectional communication by power line in high speed

•   Inquire about the on or off status of the controlled electrical appliance, feedback and show the   work status.

•   Easily and quickly set status and finish learning within 6 seconds

•   Use noise suppression circuit inside to insure the signal not be jammed.

Technical Specification:

•    Rated Voltage & Frequency: 220VAC±10%,50Hz

•    Static Power  <1W

•    Ambient Temperatures -10~50°C

•    Response Time for bidirectional signals≤ 2s

Specification

This products need to be joined with normal DTMF line and AC220V power supply.

Call in by telephone or mobile phone

1. After six times rings, voice prompt ‘Welcome to TAIYITO Long-Distance Intelligent Controlling System. Please input the passwords’
2. Input the right passwords and prompt ‘Please input the electric appliance number and command ON or OFF’
3. Press the appliance no. (Number 01-99) and controlled order (‘*’ as ON and ‘#’ as OFF, ‘0’as check the status)
4. As receiving on or off order, prompt ‘Appliance X, ON or OFF, in the command transition. Wait Please’
5. As receiving the feedback information, prompt ‘Appliance X ON or OFF’; if no information, will prompt ‘failed, please input again’

Control it by extension at home

1. Input ‘***’ to enter the extension control status by extension, prompt ‘Enter the telephone intelligent controlling system, Please input the electric appliance number and command ON or OFF. If want to setup the passwords and electronic appliance number,please press Well Number directly.’
2. Press the electrical appliance number (01-99) and controlling commands (‘*’ as on and ‘#’ as off, ‘0’as check status) by extension to control the electrical appliance. As receiving on or off order, prompt ‘Appliance X, ON or OFF, In the command transition. Wait Please’, As receiving the feedback information, prompt ‘Appliance X ON or OFF’; if no information, will prompt ‘failed, please input again’
3. Enter setup status press#, prompt ‘If want to setup the passwords,please press 1. If want to setup the electronic appliance number,please press 2. If want to return,please press Well Number’.
4. Press 1, prompt ‘Please input the passwords’; as input the new four passwords, prompt ‘The new passwords you input XXXX’. When the password setup finished, prompt ‘Please input the ringing times’, press the ring times that you hope, prompt ‘The ringing times you input X’. After the ringing times setup finished,prmop‘Please input the call-prompt electronic appliance number’,input the appliance number(01-99),prompt‘The electronic appliance number you input is X’(After this setting,when there is phone call,the call-prompt electronic appliance will be ON/OFF with the calling).
