Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > New Type Audio Cable for Audio Devices With Good Quality
New Type Audio Cable for Audio Devices With Good Quality
US$ 0.10 - 0.10
MOQ: 100 Meters
Key Specifications
Get Latest Price
Place of Origin:
Chongqing, China
Brand Name:
YUFENG
Model Number:
BV BVR BVV BVVB RV RVV
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing / Shanghai / Guangzhou / Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Colours Copper Network Cable 2/4pairs 24awg UTP Cat5e Cable 305mUS$ 0.1 - 0.3MOQ: 100 Meters -
High Speed Lan Network CableUS$ 0.1 - 0.3MOQ: 100 Meters
-
Factory Price RJ45 Ethernet White Network CableUS$ 0.1 - 0.3MOQ: 100 Meters
-
2 Core Speaker CableUS$ 0.10 - 0.10MOQ: 100 Meters
-
10M PVC Telephone Wire From ChinaUS$ 0.10 - 0.10MOQ: 100 Meters
Place of Origin
Chongqing, China
Brand Name
YUFENG
Model Number
BV BVR BVV BVVB RV RVV
Type
Insulated
Application
Overhead
Conductor Material
Copper
Conductor Type
Solid
Insulation Material
PVC
New Type 3.5mm Audio Cable for Audio Devices with Good Quality
Specifications
Type:CU/PVC
Color: Red, Yellow, Blue, Green, Purple, Gray, Black, White.
Packaging:100 meters per roll
Certification:CE,CCC,ISO9001,ISO14001,ASG CNAS
Product Description
Specifications
New Type 3.5mm Audio Cable for Audio Devices with Good Quality
Construction
Conductor |
Material |
Bare Copper/CCS |
Nom. Dia. |
7*0.16mm |
|
Dielectric |
Material |
Solid PE |
Nom. Dia. |
1.52mm |
|
Out Conductor |
Material |
85% TC/BC Braiding |
Nom. Dia. |
2.00mm |
|
Jacket |
Material |
PVC |
Nom. Dia. |
2.95mm |
Electrical Specifications
Impedance Ohm |
50 ±3 |
Capacitance Pf/m |
101±2 |
Velocity of Propagation % |
66 |
Inner Conductor DCR |
318.2 |
Outer Conductor DCR |
35.1 |
Max Operating Voltage |
1500 |
Operating Temp °C |
-40 to +85 |
