Super Quality High Pressure Chemical Equipment

Super Quality High Pressure Chemical Equipment thumbnail-1
Super Quality High Pressure Chemical Equipment thumbnail-2
Super Quality High Pressure Chemical Equipment thumbnail-3
Super Quality High Pressure Chemical Equipment thumbnail-4
Super Quality High Pressure Chemical Equipment thumbnail-5
Super Quality High Pressure Chemical Equipment thumbnail-6
Super Quality High Pressure Chemical Equipment photo-1
Super Quality High Pressure Chemical Equipment photo-2
Super Quality High Pressure Chemical Equipment photo-3
Super Quality High Pressure Chemical Equipment photo-4
Super Quality High Pressure Chemical Equipment photo-5
Super Quality High Pressure Chemical Equipment photo-6
US$ 1 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
SY
Contact Supplier Request Quote Chat Now
Jiangsu Shuo Yun Petrochemical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name SY
Model Number as per design
Dimension(L*W*H) customized
Capacity 30L-80000L
Weight 0.5-50T
After-sales Service Provided Engineers available to service machinery overseas

 Super quality high pressure chemical equipment

TRADE ASSURANCE VARIOUS KINDS OF REACTORS

Dear Customers:

        We have Trade Assurance granted by , which means you will receive 100% refund for all of the orders if the products do not meet your quality requirement or delivery time!

 We have ASME certificates and Chinese pressure vessel design and manufacturing certificates from grade 1 to grade 3


Our pressure vessel (electric, steam and thermal oil heating) is composed by cover, cylinder, jacket, stirrer, gland seal drive and support. The body and parts contacting with the materials are all made by Ocr18Ni9 or 1Cr18Ni9Ti acid-resisting stainless steel plate.
We are the professional stainless steel kettle manufacturer as well as all specifications of non-standard chemical and light mechanical equipment designer and producer. Welcome the enquiries both from home and abroad.

Super quality high pressure chemical equipmentSuper quality high pressure chemical equipmentSuper quality high pressure chemical equipmentSuper quality high pressure chemical equipment

Electric Heating Kettle
Nominal Volume L Electric
Power		 Size of Inner Kettle
φmm		 Jacket Size
Φmm		 Reducer Model Electromotor
n/kw		 Stirring Speed
r.p.m
50 4×2 KW φ400 φ600 BLD 0.8-1 1450/0.8 60-100
100 6×2 KW φ500 φ700 BLD 1.1-1 1450/1.1 60-100
300 6×4 KW φ800 φ1000 BLD 2.2-2 1450/2.2 60-100
500 9×4 KW φ900 φ1100 BLD 3-2 1450/3 60-100
1000 12×4 KW φ1200 φ1400 BLD 4-3 1450/4 60-100
2000 15×5 KW φ1400 φ1600 BLD 4-3 1450/4 60-100
3000 15×6 KW φ1600 φ1800 BLD 5.5-3 1450/5.5 60-100
 Steam Heating Kettle
Nominal Volume L Electric
Power		 Size of Inner Kettle
φmm		 Jacket Size
φmm		 Reducer Model Electromotor
n/kw
30 400 500 0.6 BLD 0.6-1 60-100
50 500 600 0.8 BLD 0.8-1 60-100
100 550 65 1.1 BLD 1.1-1 60-100
150 600 700 2.2 BLD 2.2-2 60-100
200 650 750 2.2 BLD 2.2-2 60-100
300 800 900 3 BLD 3-2 60-100
500 900 1000 3 BLD 3-2 60-100
800 1100 1200 4 BLD 4-2 60-100
1000 1200 1300 4 BLD 4-3 60-100
1500 1300 1400 4 BLD 4-3 60-100
2000 1400 1500 5.5 BLD 5.5-3 60-100
2500 1400 1500 7.5 BLD 7.5-4 60-100
3000 1400 1500 7.5 BLD 7.5-4 60-100
3500 1400 1500 7.5 BLD 7.5-4 60-100
4000 1500 1600 7.5 BLD 7.5-4 60-100
5000 1600 1700 7.5 BLD 7.5-4 60-100
6000 1800 1900 15 BLD 15-5 60-100
18000 2000 2100 15 BLD 15-5 60-100
32000 3000 3200 37 BLD 37-56A 35-59
Since user’s manufacture technique and operation condition vary, the heating type of jacket can be classified as electric-heating bar, steam and thermal oil circulation. The gland seal packing can be filler seal and mechanical seal. The stirrer has anchor, blade, turbo, impeller or gate types. Drilling number and specification or other requirements can be designed and manufactured as per users’ demands.



Why Choose us?

1. Famous Brand in the Industry

2. Best Quality Standard, most competitive Price

3. Fast Delivery time, excellent after-sales service for 2 years.

Super quality high pressure chemical equipmentSuper quality high pressure chemical equipmentSuper quality high pressure chemical equipmentSuper quality high pressure chemical equipmentSuper quality high pressure chemical equipmentSuper quality high pressure chemical equipmentSuper quality high pressure chemical equipmentSuper quality high pressure chemical equipment
