Help CenterChina High Capacity QT10-15 Automatic Concrete Block Plant
Related Products
-
QT4-20 Semi-automatic Concrete Brick Making EquipmentUS$ 40,000 - 100,000MOQ: 1 Set -
QT4-20 Semi-automatic Concrete Brick Production EquipmentUS$ 40,000 - 100,000MOQ: 1 Set
-
QT4-20 Semi-automatic Cement Block Production EquipmentUS$ 40,000 - 100,000MOQ: 1 Set
-
QT4-20 Semi-automatic Hollow Block Production EquipmentUS$ 40,000 - 100,000MOQ: 1 Set
-
New Design Concrete QT4-15 Interlocking Brick MachineUS$ 30,000 - 80,000MOQ: 1 Set
QT10-15 Main technical data:
Vibration frequency |
0~ 6000 |
Pallet dimension |
1080*850*30(mm) bamboo pallet |
Molding cycle |
15-25 |
Conversion parameter |
0~60Hz |
Specification of mould box |
1100*85 0(mm) |
Power |
57KW |
Weight |
12.7T |
Installation dimension |
13500×5000×3500(mm) |
The theoretical Production capacity:
Hollow block |
10pcs/mold (390*190*190), 17000pcs/day (8hours) |
Porous block |
24pcs/mold (240*115*90), 46 000pcs/day (8hours) |
Standard brick |
51pcs/mold (200*100*60), 97000pcs/day (8hours) |
Environmental protection paver |
28pcs/mold (240*115*53), 40000pcs/day (8hours) |
Main Raw Materials:
Fly ash, cement, sand, crash stone, additive, constrution garbage etc.
JS750 mixer
PL1200 batching machine
Production line at buyer's place:
Our service
1) Send the technicians to carry out the installation and debugging of equipment for
the foreign users with compensation.Countries or regions with unstable political
situation or in the throes of wartime are not included in our plan.
2) Train the users to command the equipment and guide them for safe production.
3) Explain the routine maintenance of equipment carefully and remove common faults.
4) We are responsible for all the repairs that caused by our quality problems within one
year’s warranty. (We will provide one set of spare parts/wear & tear parts free of charge
with shipment.)
5) For some countries whose visas are difficult obtained, customers can also send their
technicians to our company to receive free guidance and training.
6) Accept suggestions for improvement put forward by customers an earnest way.
In accordance with changes of the market, provide the products and services to meet
the user’s needs and create value for them.
7) We will make every effort to solve your problems, and your success will add new
glory to us.
