Help CenterLW-6 Tractor PTO Backhoe
Related Products
Specifications
1. with PTO PUMP AND OIL BOX.2. 3 point hitched
3. optional buckets
4. strong enough for hard work
features:
1. matched to tractors which has 3 point linkage and PTO
2. better for 4 wheeled driven tractors
3. power requirements from 18-120 HP
4. optional buckets from 200mm-800mm wide
Specs data:
Model |
LW-6 |
LW-7 |
LW-8 |
Max. Digging Depth (mm) |
1850 |
2150 |
2640 |
Max. Digging Radius (mm) |
2800 |
3360 |
3930 |
Max. Digging Height (mm) |
2500 |
3400 |
3510 |
Loading Height (mm) |
1400 |
1760 |
2000 |
Swing Arc (deg.) |
160 |
160 |
160 |
Bucket Rotation (deg.) |
160 |
160 |
160 |
Connect Height (mm) |
410 |
460 |
460 |
Connect Width (mm) |
399 |
530 |
530 |
Valve Standard Pressure |
16Mpa. |
16Mpa. |
16Mpa. |
Load Capacity (m3) |
0.036 |
0.045 |
0.054 |
Structural Weight (kg) |
620 |
650 |
680 |
Shipping Dimensions (mm) |
2200*760*1600 |
2200*780*1600 |
2200*800*1600 |
Bucket Width (mm) |
300 |
400 |
500 |
Power Required (hp) |
15-25 |
30-45 |
50-80 |
Max. Digging Length (mm) |
1410 |
1450 |
1610 |
Packing Method |
Iron Crate |
Iron Crate |
Iron Crate |
