EN Standard Asphalt Wheel Track Testing Machine

EN Standard Asphalt Wheel Track Testing Machine photo-1
US$ 8,000 - 9,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
TP
Power:
Electronic
Payment & Shipping
Payment Methods:
Port of Shipment:
XINGANG
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hebei, China
Brand Name TP
Power Electronic

Specifications

Standard:EN 12697-22
specimen size: 300x300x50mm
Pressure: 700N

Wheel track testing machine

Specifications

Wheel tracking machine for rutting ability of asphalt & asphalt-concrete materials in high temperature
max. temperature: 80 degree





1. Application:  This tester is used to test the high-temperature wheel rutting ability of asphalt mixture for the high-temperature stability performance of related mixing proportion design.



2. Characteristic: This tester is made with advanced single-chip microcomputer controlling technology, machine finishing technology and related new developping application software.





3. Main technical parameter:

  • specimen size: 300x300x50mm or other require dimension specimen
  • working method: crank connecting rod driven test wheel movement
  • ruuber hardness: 84±4   international standard
  • test wheel moving distance: 230mm±10mm
  • Load cycles: 26.5±1 cycles/min
  • loading device: the contact pressure is 0.7±0.05Mpa when the temperature is 60oC, total loading is around 78kg and adjustable
  • deformation measurement precision: 0.3%
  • heating power: 3KW
  • temperature control precision: 0.5oC
  • working temperature: 0~80oC    humity≤90%, haven't corrosive and flammable gas
  • driving motor power: 0.75KW
  • weight: 500KG

EN Standard Asphalt Wheel track testing machine
