SYE-2000 2000KN Digital Display Hydraulic Compression Testing Machine
US$ 2,500 - 3,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
C-TECH
Model Number:
SYE-2000
Payment & Shipping
Payment Methods:
Port of Shipment:
xingang
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TPZ-2 Electric Automatic Sieves Shaker,US$ 650 - 980MOQ: 1 Set -
Automatic Motorised Sand Equivalent ShakerUS$ 600 - 800MOQ: 1 Set
-
Asphalt Mixture Gyratory CompactorsUS$ 20,000 - 25,000MOQ: 1 Set
-
5m Portable Sampling Drilling Rig Hand-heldUS$ 1,000 - 10,000MOQ: 1 Set
-
BS Standard Concrete Compaction Factor ApparatusUS$ 250 - 450MOQ: 5 Sets
Place of Origin
Hebei, China
Brand Name
C-TECH
Model Number
SYE-2000
Power
Hydraulic
Usage
Strength Testing Machine
2000kN digital display hydraulic compression testing machine
For determining the compressive and flexural strength of concrete, brick, stone and other building material. It loads hydraulic pressure and is main specified of building highway and building industry. The data is automatically output, connect with computer and easy to operate.
Main features
• Meet the requirements of EN 12390-4 ASTM C39, AASHTO T22
• Tests 200, 150 and 100 mm concrete cubes and cylinders up to 320 x 160 mm diameter
• Load pacing facility fitted as standard
• Platen handling machines include BS 6073-1, EN 772-1 specification rectangular platens.
• Supplied with Windows download software.
• Meet the requirements of EN 12390-4 ASTM C39, AASHTO T22
• Tests 200, 150 and 100 mm concrete cubes and cylinders up to 320 x 160 mm diameter
• Load pacing facility fitted as standard
• Platen handling machines include BS 6073-1, EN 772-1 specification rectangular platens.
• Supplied with Windows download software.
Max load Capacity: |
2000kN |
| Dimension of upper platen | 240mm x 240mm |
| Dimension of lower platen | 300 mm x 250mm |
| Distance between platens | 320mm |
| Max. Oil pressure | 40Mpa |
| Accuracy | +1% |
| Piston Dia. X Max. travel | 250mm X 50mm |
| Power | 0.75KW |
| Overall dimension: | 900mm X 400mm X 1360mm |
| Entire machine weight | 800kg |
