LED Line--control Outdoor Facade Rgb Illuminated Bar Light

Name: LED Line--control Outdoor Facade Rgb Illuminated Bar Light
Brand: Charming
SKU: 104077237
Availability: InStock

Guangzhou Charming Lighting Co., Ltd.

US$ 5 - 10 MOQ: 100 Pieces

Key Specifications

LED Light Source:

LED chip

Input Voltage(V):

DC24

Lamp Power:

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou/Shengzhen

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source LED chip

Input Voltage(V) DC24

Lamp Power 36

Lamp Luminous Flux(lm) 1505LM

Color Temperature(CCT) Warm White

Working Temperature(℃) -20, 55

Working Lifetime(Hour) 30000

Lamp Body Material Other, polycarbonate

IP Rating IP65

Certification CE, FCC

Emitting Color RGB

Place of Origin Guangdong, China

Brand Name Charming

Model Number COL.H.001.3100

LED Line-control Linear Washer Specificaion:
Type number	COL.H.001.3100	COL.H.001.1300	COL.H.001.1301	COL.H.001.1302	COL.H.001.1304	COL.H.001.1303	COL.H.001.1306
Dimension(mm)	10005955	10005955	10005955	10005955	5005955	5005955	5005955
LED quantity	12	12	36	16	6	18	8
Max. power	36W	36W	36W	48W	18W	18W	24W
Brightness	≥672LM	≥855LM	≥1505LM	≥1405LM	≥300LM	≥420LM	≥750LM
Refresh rate	≥400	≥400	≥400	≥400	≥400	≥400	≥400
Color type	White	Full color RGB	Full color RGB	Full color RGB	White	Full color RGB	Full color RGB
Weight	1.3kg	1.3kg	1.3kg	1.3kg	0.65kg	0.65kg	0.65kg
Input voltage	DC 24V	0~24V	0~24V	0~24V	DC 24V	0~24V	0~24V
Beam angle	15	45	15	45	45	15	45
Crust material	PC
Isolating grade	CLASSE Ⅱ
Proection level	IP65
Life span	≥30,000 hours
Working temp.	-20~55℃
Connection mode	10M Ethernet cable,The 4 core waterproof extension line
Control mode	EASYPLAER+Yu tong YT-950S controller DMX512-V9 digital processor DMX512 console
Quantities of driving lamp	16
