Specifications
We export all kinds of forged flange for ten years!Welcom to your enquiry!Happy cooperation!We are pleased to give you our best quotation if you sent our your drawings & technical requirements!
We can provide you the standard & non-standard forged flange.
standard forged flange:
| Standard | |||
|
ANSI (ANSI B16.5) |
class150,300,600, 900,1500,2500, |
1/2"-24" |
slip-on(SO) welding neck(WN) socket welding(SW) threaded flange lap joint flange(LJF) blind flange(BL) |
| ANSI (ANSI B16.5) |
class150,300,400, 600,900,1500,2500 |
1/2"-24" | long welding neck flange(LWN) |
|
MSS (ASME B 16.47 SER,A) |
class150,300,400, 600,900, |
12"- 60" |
slip-on(SO) welding neck(WN) socket welding(SW) threaded flange lap joint flange(LJF) blind flange(BL) |
|
API (ASME B 16.47 SER,B) |
class75,150,300 | slip-on(SO) welding neck(WN) socket welding(SW) threaded flange lap joint flange(LJF) blind flange(BL) |
|
| AWWA C207 | classB,D,E | 4"-120" | slip-on(SO) welding neck(WN) socket welding(SW) threaded flange lap joint flange(LJF) blind flange(BL) |
DIN |
6bar,10bar,16bar, 25bar,40bar |
10mm- 1000mm |
SO,BL,WNF |
| KS (JIS) |
5K,10K,16K,20K 30K |
10mm-15000mm | slip-on(SO) welding neck(WN) socket welding(SW) threaded flange lap joint flange(LJF) blind flange(BL) |
| EN 1092-1 |
PN6,PN10,PN16, PN25,PN40,PN63, PN100 |
10mm- 3000mm |
slip-on(SO) welding neck(WN) socket welding(SW) threaded flange lap joint flange(LJF) blind flange(BL) |
Non-standard forged flange is manufactured as per the drawings.
We have our own forging shop,machining shop,heat treatment shop and provide you the relative reports.
We'd like to provide you EN 10204-2008 Type-3.1 certification,the details of which are as following.
1Chemical composition(C,Mn,P,S,Si,Cr,Ni,Mo,Cu,Cb,V,CE)
2Heat treament(quenched&tempered,normalized&tempered,normalized)
3Mechanical properties(tensile strength,yield strength,elongation,reduction of area)
4Impact test
5Hardness(reference:ASTM A370)
Dimension report will be sent to you.
Ultrasonic test (100%UT reference:Testing Standard: ASTM A388 Acceptance Standard: ASME B16.34 APPENDIX IV)
3.2 certification & Third Part Inspection(TPI) are allowed as per your requirements.
Product Marking(supplier no./part no./heat no./heat treatment no./heat treatment)
Packing(in plywood)
Test block taken from forging for mechnical property will be shipped along with your goods.
Main markets India,Europe America,southeast Asia and so on
