Specifications
payment term:L/C T/Tforging(body,body adapter,stem housing,seat ring,trunnion,plate,side piece,closure,shaft)
THI/UT/MPT
Details about this piece in the picture
Material:ASTM A350F2
Chemical composition:
C=0.19% Mn=1.00% P%=0.018 S=0.008% Si=0.28% Cr=0.03% Ni=0.01%
Mo=0.01% Cu=0.01% Nb=0.01% Ti=0.006% V=0.01%
Mechanical properties:
Y.E.=371Mpa T.S.=566Mpa E%=31.4% R.A.%=70.7%
Hardness: from 160HB to 168HB
-46 Impact test: 146
Heat treatment:Quenched (930 x 2.5Hrs.)& Tempered(670 x 3.25Hrs.)
1 We have our own free forging shop,heat treatment shop, machining shop.
2 We will give you our BS EN10204 3.1 certification & Ultrasonic Testing.
3 We also can accept Magnetic Partial Test,Third Party Inspection(BV),as your requirements.After International Third Party Inspection,we will offer you our BS EN10204.3.2 certificate.
4 We have portable appatatus to do radioactive contamination examination.
If you want to kown more about our company ,I will have the pleasure of serving you .Please contact me at any time!
