Home > Industrial Equipment & Components > Fastener & Fitting > Flange > ANSI B16.5 Class1500 A105 Free Forged Body Adapter

ANSI B16.5 Class1500 A105 Free Forged Body Adapter

US$ 30 - 30,000 MOQ: 3 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Shanxi, China

Brand Name:

JHD

Model Number:

10"Full Bore

Contact Supplier Request Quote Chat Now

Taiyuan Jiahongda Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjin

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanxi, China

Brand Name JHD

Model Number 10"Full Bore

Application connection

Dimensions ANSI B16.5 class1500

Specifications

This is one of free forged body adapters for our clients.Please contact me if you are interested in our products.

We are pleased to give you our best price as per your drawings!

It is our sincere wish that we will have the privilege of serving you soon!

Chemical composition

Element		C%	Mn%	P%	S%	Si%	Cr%	Ni%	Mo%	Cu%	V%	CE
Required	Min		0.6			0.10
Required	Max	0.23	1.05	0.035	0.035	0.35	0.30	0.40	0.12	0.40	0.08	0.43
Heat No.:11703917		0.20	1.01	0.016	0.0062	0.27	0.043	0.019	0.043	0.011	0.016	0.39

Heat No. 11703917 Cu+Ni+Cr+Mo+V=0.132% Cr+Mo=0.086%

Mechanical properties

HT No.

Y.S.(Mpa)

T.S.(Mpa)

E.%

R.A.%

HARDNESS

(BHN)

≥250

≥485

≥22

≥30

150-187

ZJZ110802

362

536

29.8

73.2

155

Heat treatment

Heat No

HT No.

Heat Treatment Process

11703917

ZJZ110802

Normalized

900°CX3.83HRS

&AIR COOLED

Tempered

600°CX4.33HRS

&AIR COOLED

Now I’d like to introduce our products,relevant reports and certifications to you..And it is our sincere wish that we have the privilege of serving you soon.

Material: Forged Carbon Steel, Stainless Steel , Duplex Stainless Steel , Low Alloy Steel

(Like A105,LF2,LF6,F6a,F304,F316,F22,F51,F11,F317L,F60…)

Main products:forged flange(slip-on flange,welding neck flange,socket welding flange,threaded flanged,lap joint flange,blind flange,ring joint flange,long welding neck flange) & free forgings(body,body adapter,stem housing,trunning plate,seat ring…)

Main market:India,America…

EN10204 3.1certification is provided,containing the following details.

A Chemical composition(C,Mn,P,S,Si,Cu,Ni,Cr,Mo,V,CE)

B Mechanical properties(yeild strength,tensile strength,elongation,reduction of area)

C Heat treatment(normalized,tempered,quenched,anneal)

D Hardness(standard:NACE MR0175)

E Impact test

Ultrasonic Test report is also provided.

UT testing standard:ASTM A388

UT acceptance standard: ASME B16.34 APPENDIX IV

UT equipment: HS610e

UT technique: Straight/Contact

FREQUENCY:2.5MHz

Probe Used: 2.5P Φ20

Test Blocks:Φ3

SENSITIVITY: Φ3+13dB(Φ6.4)

Couplant: OIL

3.2certifification&MPT report can be provided,after international Third Part Inspect(TPI) is witnessed by BVSI.

Dimension report is sent to you.

Test block from the product for mechanical testing is shipped along with your product.

Marking of Forging: Sr.No./Supplier Code/Item Code/Material Grade & Material Heat No.,Heat Treatment Lot No.

Minimum Reduction Ratio of Product is 4:1

Packing:in polywood Suitable to sea shippment

Our factory pay more closed attention to our products’ quality and stage inspection.Based on that, we have a great success in the past ten years.We have our own factory for twenty years.If you are interested in our products and wanna establish business ralationship with us,we are pleased to quote you our best price as per your drawings you require.

Welcome to your enquiry!
