| Packing | |||||||||||||||||||||||||||||||||||||||||||||
|
| |||||||||||||||||||||||||||||||||||||||||||||
Technical Parameter | |
Electric Kettle Heating Tube | |
Body Material |
T2 red copper |
Pipe Size |
Φ8.0 |
Tube wall thickness |
0.4~0.5mm |
Thermostat System |
STRIX control,satisfying the various demand of compatibility testing |
Conductive cap connection type |
squeeze riveted to withstand tension of 5 kg |
Key size to temperature control |
3.6±0.4;13.1±0.25;14.1±0.2 |
Watt |
customized |
Voltage |
Customized |
Overall Dimensions |
OEM, customized in drawing or samples. |
Electrical Performance |
AC1500V/0.5mA.3S;DC500V 100MΩ;Leakage current<0.5mA |
Life Time |
Power on 0.5 time voltage boil dry until trip,then water cooling within 5 seconds,non-yellowing on tube surface.Coating without upwarping and sparkling. |
Warranty |
TWO year |
High- pot test |
1500V/2mA/1S |
Resistance insulation |
100MΩ MIN |
Leakage current |
0.5mA MAX |
Surface Treatment |
electronickelling |
Hydraulic testing |
withstand 1.2MPa pressure test no leakage |
flange material |
1.0mm,brass |
welding of flange technique |
Flange and pipe joint with brazing, withstand 0.4MPa pressure test no leakage |
| 1.Q: Are you a trading company or .a factory? |
| A:We are a factory. |
| 2.Q:Where is your factory located? How can I visit there? |
|
A:Our factory is located in Changshu of Suzhou city, Jiangsu province, China. It takes about 2 hours from Shanghai to our factory by car. All the client, from home or abroad, are warmly welcome to visit us. |
| 3.Q:How can I get some samples? |
| A:We are honored to offer you samples,will send to you by express. |
| 4.Q:Are your products customized? |
|
A:Yes, the products in the website are only common type or the customized types ordered by our customers, we can supply products according to your samples and drawings. |
| 5.Q: How does your factory control quality? |
|
A:Quality is priority, our QC always keep step to quality control during production process,all of the orders will be deliveried after QC passed. |
