Long Mechanical Life WL Crane Limit Switch
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
WEHOPE
Model Number:
WL
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO/SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Stainless Steel Idler Wheel, Punch and Spring CSA Limit SwitchNegotiableMOQ: 100 Pieces -
CSA Roller Arm Type Limit SwitchNegotiableMOQ: 100 Pieces
-
CE Certificate CSA Types of Electrical Limit SwitchesNegotiableMOQ: 100 Pieces
-
China Wholesale With ROHS/CE Certificate Limit Switch 8108NegotiableMOQ: 100 Pieces
-
Wholesale Long Life Electrical Switch CLS Roller Plunger Limit SwitchNegotiableMOQ: 100 Pieces
Place of Origin
Zhejiang, China
Brand Name
WEHOPE
Model Number
WL
Protection Level
IP67 NEMA:3,4,13
Operating Temperature
-10℃ to +80℃
Max. Current
10A
Max. Voltage
250V
Main technical parameters for WL crane limit switch
| Model | WL-CA2-2 WL-CA12- 2-Q |
WL-CA32- 41-43 |
WL-CL | WL-D | WL-D1/D2 /D3 |
WL-NJ/ NJ-30/ NJ-2/ NJ-S2 |
| Triggering | 30°convex trigger |
30°convex trigger |
Any moving part |
At the end | 30°convex trigger |
Any moving part |
| Contact operation |
Contacts attract Contracts separate
|
|||||
| Max triggering speed |
1.3m/s | 0.5m/s | 1.3m/s | |||
| Max restoring force |
1360g | 1200g | 142g | 2720g | 2720g | 120g |
| Min restoring force |
227g | 28g | 910g | 910g | 50g | |
| Weight (kg) | 0.330 | 0.340 | 0.300 | 0.251 | 0.251 | 0.286 |
Characteristics Of Contact Module
| Rated operating characteristics |
Inductive load: ~AC-15: A300(Ue=240V, le=3A):1 the=10A ~DC-13: Q300(Ue=250V, le=0.27A) comply with IEC60947-5-1 A appendix table A,EN60947-1 |
| Rated insulation voltage |
Among homopolar terminals: AC 1000V(600V), 50/60Hz 1min Between charged metal part and earth wire: AC2000V(1500V), 50/60Hz 1min Uimp 2.5kV Among terminals and non-charged metal part: AC2000V,50/60Hz 1min Uimp 2.5kV |
| Insulation resistance | >100MΩ, at 500VDC 100MΩ above (megohmmeter of 500VDC) |
| Operating frequency | 120 times/min |
| Electrical life | 750,000 times |
| Contact resistance | ≤25MΩ |
Environmental Characteristics
| Normative reference |
Product | IEC60947-5-1, EN60947-5-1, UL508, CSAC22-2N°14 |
| Components | IEC60204-1, EN60204-1 | |
| Ambient temperature |
operation | -10~+80℃ |
| Storage | -40~+80℃ | |
| Vibration resistance | Comply with IEC60068-2-6 | 10-55Hz complex amplitude 1.5mm |
| Shock resistance | Comply with IEC60068-2-27 | Maximum 300m/s2 (30G Less than) |
| Degree of protection | IP67 NEMA:3,4,13 | |
| Mechanical life | 15,000,000 times |
The detail of WL crane limit switch
Product introduction
1.Double-circuit type of limit switch, is widely used
2.With strong aluminum cast outer shell
3.High mechanical strength
4.Structure preventing oil, water and pressure
5.Indicating plate with setting position is installed in it, so it is easy to maintain
6.Various of actuators is taken convenience for using
7.Built-in contact stand has double-spring, so it has long mechanical life
