Stainless Steel Idler Wheel, Punch and Spring CSA Limit Switch

Name: Stainless Steel Idler Wheel, Punch and Spring CSA Limit Switch
Brand: WEHOPE
SKU: 103988897
Availability: InStock

Yueqing Houpu Trading Co., Ltd.

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

WEHOPE

Model Number:

CSA

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO/SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name WEHOPE

Model Number CSA

Protection Level IP66

Operating Temperature -5℃~+65℃ (with no icing)

Max. Current 10A

Max. Voltage 250V

Main technical parameters for Stainless steel idler wheel, punch and spring CSA Limit Switch

Characteristic/Application

Double Break Mechanism	INO+INC Force Break snap action
Rated Voltage / Current	10(4)A, 125, 250VAC / 6(2)A, 380VAC For inductance Load, Cosφ=0.4
Contact Resistance	25mΩ max. (initial value)
Insultation Resistance	100mΩ min. (at 500VDC)
Dielectric Strength	1000VAC, 50/60 Hz for 1 minute between terminals of the same polarity
	1500VAC, 50/60 Hz for 1 minute between current-carrying and non-current-carrying metal parts
	1500VAC, 50/60 Hz for 1 minute between each terminal and ground
Electrical Life	500,000 at 10A 250VAC Resistive
Mechanical Life	10, 000, 000 operations min. (under rated conditions)
Operating Speed	5mm/s to 0.5m/s
Degree of Protection	IP66
Ambient Temperature Rised	Max 30℃ over ambient temperature at rated voltage/current
Conformed Standards	Cenelec EN 50041, EN 50047, IEC 337-1, VDE 0660
Operating Temperature	‘-5℃~+65℃ (with no icing)
Storage Temperature	’-5℃~+65℃ (with no icing)
Ambient Operating Humdity	95% RH Max.
Shock Resistance	Mechanical durable: 1000m/s2 min.
Shock Resistance	Malfunction: 300m/s2 min.
Vibration Frequency	Malfunction: 10 to 55Hz, 1.5mm double amplitude
Terminal Screw Torsional Force	6-8 kgf-cm
Other Screw Torsional Force	Cover 12-14 kgf-cm/Head 8-9 kgf-cm/Mounting 50-60 kgf/cm
Bare Wire Diameter	φ2 Max
Cable Diameter	φ12 Max(IP 65 if use cable φ8-9)
Note: Product with spring, its usable range of operating part is within one third of the whole spring length from the front end of spring.
