Specifications
1.Fixed speed OEM pumps
2.Flow rates:0-36mL/min
3.Speed:0-100 rpm,
NEW PRODUCT – Peristaltic Liquid Pump with Silicone Tubing. Move fluid safely from here to there with this very nice little pump. Unlike most liquid pumps, this is a peristaltic type – the pump squishes the silicone tubing that contains the liquid instead of impelling it directly. The upshot? The pump never touches the fluid which makes this an excellent choice for any food/drink/sterile based pumping such as for making drink-bots or gardening robots!
The pump is basically a geared down DC motor, so it has a lot of torque. Inside the pump is a ‘clover’ pattern of rollers. As the motor turns, the clover presses on the tube to press the fluid though. The pump does not need to be primed and in fact can self-prime itself with water a half meter with ease. You can PWM the motor to speed up or slow down the flow rate and if you connect the motor the other way it will move fluid the other direction. Works great with either a power transistor (basic on/off) or a motor driver chip .
Please note The pump comes with a bit of silicone tubing already installed and two 1/2 meter pieces attached on with barbed connectors. However, the silicone tubing is not sterile and might be dirty on its way to you. Before using, the tubing must be sterilized! The included tubing is also not rated FDA or USDA compliant and is only meant for basic testing of the pump. If you need to purchase FDA/USDA compliant tubing for use with your food-hacking project ,PLS CONTACT US!
Product Introduction
This pump can work with 12V or 24V battery,
1.The ZW100 pumps have superb features built-in and flexible design to meet specific customer needs.
2.Flexible rotor assembly, occlusion can be adjusted automatically, which give this OEM peristaltic
3.pump a longer life.
Typical application
1.Ink conveying
2.Supporting the environmental protection equipment
3.Fermenter supporting
Functions and features
1.The ZW100 pumps heads are easy-to-use, offers trouble-free performance and provide flow rates for up to 1900 ml/min for continuous use
2.Small compact size and robust design
3.Trouble-free continuous tube loading in seconds
Specifications | |
Speed |
100 rpm, |
Flow rates |
0-36ml/min |
Speed control |
Rotary encoded switch |
Power supply |
DC12V 24V 3V 6V |
Operating condition |
Temperature 0 to 40°C, relative humidity < 80% |
Weight |
0.3Kg |
Company information
Baoding chuangrui precision pump Co.,Ltd was founded in 2006,is now mainly engaged in the peristaltic pump research and development ,production ,marketing;and related fluid precision control of the stepper motor ,drives,controller of research and development ,production and sales.Enterprise covers an area of more than 1000 square meters of modern production workshop ,more than 50 sets of production equipment.At present ,we have succeeded in bringing the ARM,DSP ,FPGA,CPLD technology application in the research and development of new products ,such as improving the comprehensive performance of the product.
Our Exhibition
Packaging
Shipping
Our peristaltic pump with 1 year warrenty and lifetime maintenance.
We can do the OEM PERISTALTIC PUMP as your special requirements.
To help u send the right tube and motor ,before purchase ,pls confirm the details as below:
1.What flowrate you need ? ml/min
2.What kind of liquid you will transfer ? does it corrosive ?
Question 1: Can I order custom peristaltic pump with my own design & logo?
Answer: Definitely yes.
Question 2: Can I order a sample first before mass production? How can I place a sample order?
Answer: Surely you can order a sample first. And there will be some sample cost, charged based on your design. We will make the sample pump for you after payment received and take pictures for your reference once finished. If you want to see the actual sample, we can send the sample to you while freight cost is yours.
Question 3: How soon can I get a sample made? How can I make payment?
Answer: For simple design sample, it generally takes about 7-15 days to get samples made. While it will take a longer time for design, make a mold, assemble, actual test. etc. Payment can be made through T/T, paypal or Western Union.
Question 4: How can I get my peristaltic pump if I place the order to you?
Answer: That depends on the quantity your ordered. 1 to 100 pieces, the pumps will be shipped to you by express(DHL, Fedex, etc.); 100 or more, mostly by air or by sea.
Question 5: Can I buy the tube separately?
Answer: Of course Yes. for the silicone tube 15 meters per roll, or you can buy 1 or 2 meters. No problem.
Pls contact Ella Xu.0086-15633705132 or leave message to us.We will reply u asap we get it.
And other question, pls feel free to contact me.
Ella Xu
Skype ID : ella-crpump
QQ : 507183200
Wechat :ellaxu1988
Tel :15633705132
Welcome to begin the trade assurance order with us . we'll try our best to satisfy you .Let's begin !!!
