Low Price Electric Valve Air Valve Control Valve Solenoid Valve 4V330C-10 4V300 Series
US$ 2 - 10
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Type:
Other, Valves, Electric air control solenoid valve
Place of Origin:
Zhejiang, China
Model Number:
4V330C-10
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO/SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Low Price Solenoid Valve Electric Valve Pneumatic Valve 3V310-10 3V300seriesUS$ 2 - 10MOQ: 10 Pieces -
Low Price Water Solenoid Valve 2W SeriesUS$ 2 - 10MOQ: 10 Pieces
-
Low Price Solenoid Pulse Valve AMD-I-20 AMD SeriesUS$ 2 - 10MOQ: 10 Pieces
-
Low Price Mini Manual Valve Pneumatic Check Valve Pneumatic Throttle Valve RE-03 RE SeriesUS$ 2 - 10MOQ: 10 Pieces
-
Low Price Air Quick Coupler SSL SeriesUS$ 2 - 10MOQ: 10 Pieces
Type
Other, Valves, Electric air control solenoid valve
Place of Origin
Zhejiang, China
Model Number
4V330C-10
Brand Name
WEHOPE
Specifications
1.Many years experiences.2.High quality , favorable price.
3.Fast delivery , best service.
Electric air control solenoid valve
Specification
| Type/Item | 4V310-08 | 4V320-08 | 4V330C-08 | 4V330E-08 | 4V330P-08 | 4V310-10 | 4V320-10 | 4V330C-10 | 4V330E-10 | 4V330P-10 | ||
| Working medium | Air (filtered by 40 m filtering net) | |||||||||||
| Action type | Inner pilot type | |||||||||||
| Position no. | Five-way two-position | Five-way three-position | Five-way two-position | Five-way three-position | ||||||||
| Effective sectional area | 25mm²(Cv=1.4) | 18mm²(Cv=1.00) | 30mm²(Cv=1.68) | 18mm²(Cv=1.00) | ||||||||
| Pipe dia. | Air inlet= Air outlet=Exhaust =PT1/4 | Air inlet= Air outlet=PT3/8 Exhaust=PT1/4 | ||||||||||
| Lubricating | Not need | |||||||||||
| Applicable pressure | 0.15~0.8MPa(21~114Psi) | |||||||||||
| Max withstand pressure | 1.2MPa(170Psi) | |||||||||||
| Working temperature | -5~60°(23~140 F) | |||||||||||
| Voltage range | -15%~+10% | |||||||||||
| Power consumption | AC: 3.5VA DC: 2.5W | |||||||||||
| Thermal endurance class | B | |||||||||||
| Protection degree | IP65(DIN40050) | |||||||||||
| Type of electrification | Terminal type and wire outlet type | |||||||||||
| Max action frequency* | 4/S | 3/S | 4/S | 3/S | ||||||||
| Excitation time | 0.05 | |||||||||||
| Weight | 310g | 400g | 540g | 540g | 540g | 310g | 400g | 540g | 540g |
540g
|
||
*Note The max action frequency is in the no-load state.
Symble
Outline dimension
| Symbol / Type | A | B | C | D | E | |
| 4V330-08 | PT1/4 | PT1/4 | 22 | 83.9 | 0 | |
| 4V330-10 | PT1/4 | PT3/8 | 24 | 82.9 | 4 |
|
Why us
• 1. We Yueqing Houpu has best supply and favorable price.
• 2.Better cost control: Relatively cheap labor and strict quality control.
• 3.100% pre-tested; 1:1 replacement.
• 4.Various kinds of specifications can be customized.
• 5.Perfect after sale service.
If you have any interest .please kindly feel free to contact me.Thanks~
Product show:
