Help CenterSmall Size Water Source Heat Pump
Related Products
-
Ultra-High Temperature Ground Source Heat PumpNegotiableMOQ: 1 Set -
Ground Source Heat PumpNegotiableMOQ: 1 Set
-
Water Cooled Water Chiller and Heat PumpNegotiableMOQ: 1 Set
-
Ground Source Heat Pump for the Ultra-tempNegotiableMOQ: 1 Set
-
Small Water Source Heat Pump (muti-function Type)NegotiableMOQ: 1 Set
Specifications
GSHP 6.5TBF - 210BCooling capacity: 6.0 - 205.2kW
Heating capacity: 7.2 - 237.6 kW
Small Size Water Source Heat Pump(R410a)
GSHP 4.5TAF - 110TAF
Cooling capacity: 4.5 - 106.4kW
Heating capacity: 5.22 - 123.4 kW
FEATURES
STRUCTURE
Panels and frame are made from galvanized steel protected with polyester powder painting to ensure total resistance to atmospheric agents.
HERMETIC COMPRESSORS
Single phase type (mod. 4.5÷6.5) and 3-phase (mod.10÷110) scroll type compressors, with built-in thermal overload cut-out and crankcase heater, mounted on rubber vibration dampers.
Mod. 10 and 12 are available with single phase compressors.
EVAPORATOR
High efficiency plate heat exchanger, factory insulated with flexible close cell material.
CONDENSER
High efficiency tube in tube heat exchanger, factory insulated with flexible close cell material.
REFRIGERANT CIRCUIT
Copper tube connection with charge valves, filter,thermostatic expansion valve (capillary for mod. 4.5÷25 for standard conditions), gas-liquid separator, high pressure switch and low pressure switch.
The heat pump units are complete also with 4-way valve and one way valve.
HYDRAULIC CIRCUIT
Built with user side and source side water inlet/outlet connectors, water discharge connectors, air vent valve,for mod.8÷38 the user side is complete also with expansion vessel, water pump and water flow switch.
ELECTRIC PANEL
Consists of:
(1)Compressor contactor,
(2)Compressor protection breaker,
(3)User side water pump contactor (for mod.4.5÷38),
(4)User side water pump breaker (for mod.4.5÷38),
(5)Microprocessor with function display.
OPTIONAL
(1)Sight glass which must be installed in factory,
(2)Source side water flow switch,
(3)Source side water pump,
(4)Anti-vibration rubber,
(5)Metallic filter for the water circuit.
(6)Desuperheater as optional
