Specifications
Modular Water Cooled Water Chiller and Heat PumpGSHP 90K-160K
Cooling capacity: 90 - 160 kW
Heating capacity: 82 - 168 kW
FEATURES
The master module can work independently or togetherwith up to 7 slave modules, flexible design, stable performance, easy maintenance.
Reusable: using solar energy stored in earth as cooling & heating source.
Panels and frame are made from galvanized steel protected with polyester powder painting to ensure total resistance to atmospheric agents.
3-phase scroll type compressor, with built-in thermal overload cut-out and crankcase heater, mounted on rubber vibration dampers.
Shall and tube type evaporator, factory insulated with flexible close cell material.
Shall and tube dry expansion type condenser, factory insulated with flexible close cell material.
The refrigerant circuit is complete with filter drier, direct expansion valve, high and low pressure switch.
Acting as multi-function unit such as cooling, heating, with heat recovery function producing hot water for domestic use.
LCD display as standard
Automatic operation dramatically reducing maintenance cost thanks to reliable microprocessor system.
Wide application as hotel, apartment, villa, factory, shopping center, office building, school, etc.
ELECTRIC PANEL
consists of:
(1)Compressor breaker,
(2)Compressor contactor
(3)Phase sequence relay
(4)Control circuit breaker
(5)Microprocessor with function display
OPTIONAL
(1)Desuperheater as optional
(2)Electronic controller with BMS system.
