Home > Transportation > Elevator & Funicular Car > Passenger Elevator > Passenger Elevators(EC-19)

Passenger Elevators(EC-19)

Name: Passenger Elevators(EC-19)
Brand: Edunburgh
SKU: 103971945

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

Edunburgh

Model Number:

EDL-808K/VF

Contact Supplier Request Quote Chat Now

Shanghai Edunburgh Elevator Group Inc.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name Edunburgh

Model Number EDL-808K/VF

Usage Car Elevators

Elevator Type Passenger Elevators

Specifications

Passenger Elevator
capacity:1000kg/1250kg/1350kg
persons:13-18
speed:1.75-4.0m/s.

Adopting the advance high speed gearless magnetic synchronized traction machine, its control driving system is VVVF compensated by auto high speed moment to achieve lowest noise.

Advance CAN micro computers network control system, with main board BT304 from Germen Edunburgh as its core, can control 16 elevators as a group. The advance double 32 bits CPU in the world, can achieve duplex or group control with only simply connecting one CAN communication interface controller without separate group control cabin

Option: remote monitoring system and charge function of IC cards.

Option: energy return device, wireless information transmitting and analyzing system.

Large car: with max capacity of 21 persons, can meet the speed request between 1.75m/s-4.0m/s

Rated load	Persons	Rate speed	Net Dimension of Car	Car height	Dimension of hoistway	Dimension of Door Opening	Over head	Pit Depth
kg		V(m/s)	AA×BB		AH×BH	JJ×HH	OH	PD
1000	13	2	1600×1500	2500/2600	2300×2300	900×2200(2300)	4600/4700	1750/1750
		2.5					4800/4900	1900/1900
		3			2450×2350		5200/5300	3100/3100
		3.5					5500/5600	3300/3300
		4					5900/6000	3750/3750
1250	16	1.75	2000×1400	2350/2438 /2500/2600	2500×2100	1100× 2100(2200)(2300)	4300/4300 /4300/4400	1700/1700 /1700/1700
		2		2500/2600	2800×2200	1100× 2200(2300)	4600/4700	1750/1750
		2.5					4800/4900	1900/1900
		3			2900×2300		5200/5300	3100/3100
		3.5					5500/5600	3300/3300
		4					5900/6000	3750/3750
1350	18	1.75	2000×1500	2350/2438 /2500/2600	2500×2200	1100× 2100(2200)(2300)	4300/4300 /4300/4400	1700/1700 /1700/1700
							4600/4600 /4600/4600
		2		2500/2600	2800×2300	1100× 2200(2300)	4600/4700	1750/1750
							4700/4700
		2.5					4800/4900	1900/1900
							5100/5100
		3			2900×2400		5200/5300	3100/3100
		3.5					5500/5600	3300/3300
		4					5900/6000	3750/3750
