Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | HS | Model Number: | HS-MMS4040 III |
Product Description
VGA Matrix SwitchDigital Matrix Switch
VGA Switcher VGA Signal Switcher
LCD screen!
Professional choice!
1
Product Introduction:
HS-MMS4040III is a mixed signal matrix switch, which supports up to 40-channel video signal input and 40-channel video signal output.
It converts and quickly switches 40 kinds of HDMI/DVI-I/VGA/YCBCR/CVBS/SDI signals to one or multiple HDMI/DVI-I/VGA channels. Internally, it is using HD digital signal transferring to ensure high fidelity output which makes picture much more clear and vivid.
RS-232 and IP/TCP network interface add convenience to computer remote control system and various remote control devices.
Typical applications
Mainly used for monitoring centers, radio and TV projects, multimedia conference rooms, large-screen display engineering, audio-visual education, command and control centers, and other places.
Features:
- Support up to 40 channels HDMI/DVI-I/VGA/YCBCR/CVBS/SDI signal input and 40 channels outputs.
- Video signal input interfaces support HDMI/DVI-I/DB15/CRA/BNC, HDMI/DVI-I interfaces are compatible with Blue ray signal.
- Video signal output interfaces support HDMI/DVI-I/DB15. HDMI/DVI-I support cables at least 20 meters.
- Video bandwidth: 405MHZ, digital interface bandwidth: 2.25GHZ.
- Long-distance transmission signal distortion compensation technology.
- Real time input signal status monitoring; display connection status of current input signal.
- Real time output loading monitoring; display connection status of output channel.
- Support fast switching operation.
- Programmable logic circuits support interactive switching freely.
- Power off memory function for last time signal switching status.
- 7 inch full-color programmable LCD touch panel operation.
- 1 RS-232 interface.
- 1 IR remote control interface.
- Built-in universal power supply 110/220V(100V-240V).
- Standard 19inch rack, 8U high-grade aluminum metal case.
2
Double polyfoam inside with double carton.
Export carton with bundle strip.
Courier or air or sea freight delivery.
3
Our company insisting on its motto "excellence pursuance, perfect service". All the products have passed CE, FCC, ROHS and ISO 9001.
4
Established in 2003, Hangzhou Hengsheng Electronic Technologies Co., Ltd is a high-tech company specializing in intelligent control systems, image stitching processing systems, matrix switching systems, and multimedia peripherals' research and production.
5
1) What's the minimum quantity of an order for your goods?
MOQ is 1 piece.
2) What's the payment terms?
Payment term: T/T, Western Union, Escrow, etc.
3) How about your after-sales service or value added service?
We can provide accessories for free within 12 months.
We are the professional manufacturer of matrix switcher, any requirement please feel free to contact us.
