Help CenterCNC High Speed Label Die-cutting Machine WJMQ-350B
Related Products
Specifications
CNC High Speed Label Die-cutting Machine WJMQ-350B1.Max.Speed:250 times/min
2.Power:220v/2.2kw
3.Weight:2100kg
CNC High Speed Label Die-cutting Machine WJMQ-350B
1. Electric Control System: The main control unit adopts imported electric components, which ensures accurate feeding and easy operation. The registration sensor ensures high die-cutting accuracy.
2. Electromagnetic clutch used for crank shaft driving, enables the machine to run at a low speed.
3. The main driving unit uses tin bronze bush, which reduce the pair clearance and increase the bearing capability. The automatically cycling oil-supply system ensures the stable pressure and prolongs the lifespan of the machine.
4. The machine can also be equipped with two station die-cutter, hot stamping machine and lateral or longitudinal perforator according to the demands of customer.
5. The machine can do film laminating, simultaneous front and back side die-cutting or stamping, perforating, stripping, delivery (or slitting) at one time, with high efficiency and rare rejects.
Technical Variables
Paper Width |
mm |
350 |
450 |
Max Die-cutting Size |
mm |
340*340 |
440*310 |
Max Die-cutting Speed |
Times/min |
250 |
|
Main Power |
KW(3 phase or 1 phase)50/60HZ |
2.2 |
2.2 |
Precision |
mm |
±0.1 |
±0.1 |
Net Weight |
kg |
2100 |
2600 |
In the field of label printing machines, we have been issued the following certificates and have been honored with many awards, such as:
Type of Certificate |
Quality management certificate: ISO 9001: 2008 standard |
CE: CE Certificate |
Type of Honor |
Science & Technology Progress Award of Tangshan |
The Title of Famous Trade Mark of Hebei Province |
National SME Technology Innovation Fund for Projects to Support Enterprises |
Enterprise Technology Center of Hebei Province |
Host Reviser of National Standard on “Rotary Printing Press Industry Standard” in Year 2011 |
One of the Top Ten Creative Brands of Printing Press Industry of Year 2010 |
Excellent Performance Award of China Label Industry in Year 2009 |
Famous Brand of Hebei Small & Medium-Sized Enterprises |
Good Quality and Credit Standing Demonstrating Enterprise |
