Specifications
Cisco Integrated Services Routersw/ 802.11 a/b/g/n FCC Compliant
2 onboard GE, 2 EHWIC slots
IP Base
Cisco 1941 Series Integrated Services Routers
The platforms are architected to enable the next phase of branch-office evolution, providing rich media collaboration and virtualization to the branch while maximizing operational cost savings The Integrated Services Routers Generation 2 platforms are future-enabled with multicore CPUs, Gigabit Ethernet switching with enhanced POE, and energy monitoring and control capabilities while enhancing overall system performance. Overall, the Cisco 1900 series offer unparalleled total cost of ownership savings and network agility through the intelligent integration of market leading security, unified communications, wireless, and application services.This Cisco 1900 series integrated services router offers embedded hardware encryption acceleration, optional firewall, intrusion prevention, and application services. In addition, the platforms support the industries widest range of wired and wireless connectivity options such as T1/E1, xDSL, 3G, and GE.
Architectural Features and Benefits
Architectural Feature |
Benefits |
Modular Platform |
1,The Cisco 1941 Series ISR are highly modular platforms with multiple module slots to provide connectivity and services for varied branch network requirements. 2, The ISRs offer an industry-leading breadth of LAN and WAN connectivity options through modules to accommodate field upgrades to future technologies without requiring replacement of the platform. |
Processors |
The Cisco 1941 Series is powered by high-performance multi-core processors that support growing demands of branch office networks by supporting high throughput WAN requirements. |
MultiGigabit Fabric |
The Cisco 1941 introduces an innovative MultiGigabit Fabric (MGF) which allows for efficient module to module communication, enabling direct services interactions across modules while reducing the overhead on the router processor. |
|
Embedded IPSec/SSL VPN Hardware Acceleration |
1, Embedded hardware encryption acceleration is enhanced to provide higher scalability, which, combined with an optional Cisco IOS Security license, enables WAN link security and VPN services (Both IPSec and SSL acceleration). 2, The onboard encryption hardware out-performs the Advanced Integration Modules of previous generations. |
|
Integrated Gigabit Ethernet Ports |
All onboard WAN ports are 10/100/1000 Gigabit Ethernet WAN routed ports. |
|
Innovative universalserial- bus (USB)-based console access |
1, A new, innovative, mini-B USB console port supports management connectivity when traditional serial ports are not available. 2, The traditional console and auxiliary ports are also available. Either the USB-based console or the RJ-45-based console port can be used to configure the router. |
|
Optional Integrated Power Supply for Distribution of Power Over Ethernet (PoE) |
An optional upgrade to the internal power supply provides in-line power (802.3af-compliant Power-over-Ethernet [PoE] and Cisco standard inline power) to optional integrated switch modules. |
Integrated Wireless LAN |
1, The Cisco 1941 offers a secure integrated access point in a single device. 2, Integrated access point is based on the IEEE 802.11n draft 2.0 standard that uses MIMO (Multi-Input, Multiple-output) to improve coverage for existing 802.11a/ b/g clients and new 802.11n clients. 3, The Cisco 1941 supports dual radios—802.11 b/g/n and 802.11a/n and is capable of operating in both autonomous and unified modes. |
---------------------
Item Number: cisco1941W-A/k9
Description:
Cisco 1941 Router w/ 802.11 a/b/g/n FCC Compliant, 2 onboard GE, 2 EHWIC slots, 256MB CF default, 512MB DRAM default, IP Base
Condition: New Sealed
Waranty: 1 Year
--------------------------
Our Services
==>Trusted by 5000+Worldwide Buyers
==> Huge Inventory in Stock
==>Up to 1 Year Warranty
==>Save up to 50%-98% off GPL
==>Cisco Certified Internetwork Expert Support 7X24 Hours
==>Flexible Payment & Shipment
==>100% Money Bank Guarantee
--------------------------
Product Specifications of Cisco 1941W-A/K9 Integrated Services Router
| Device Type | Wireless Router |
| Enclosure Type | Desktop, rack-mountable - modular - 2U |
| Connectivity Technology | Wired , Wireless |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n |
| Network / Transport Protocol | IPSec, PPPoE, L2TPv3 |
| Routing Protocol | OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), IPv4-to-IPv6 Multicast |
| Remote Management Protocol | SNMP, RMON |
| Encryption Algorithm | SSL |
| Features | Firewall protection, VPN support, MPLS support, Syslog support, content filtering, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Dynamic Multipoint VPN (DMVPN), Web Services Management Agent (WSMA), NetFlow |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n ,IEEE 802.3, IEEE 802.1Q, IEEE 802.3af, IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag, ANSI T1.101, ITU-T G.823, ITU-T G.824 |
| RAM | 512 MB (installed) / 2 GB (max) |
| Flash Memory | 256 MB (installed) / 8 GB (max) |
| Status Indicators | Link activity, power |
| Expansion / Connectivity | |
|---|---|
| Interfaces | 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Management : 1 x console - RJ-45 ¦ Management : 1 x console - mini-USB Type B ¦ Serial : 1 x auxiliary - RJ-45 ¦ USB : 2 x 4 PIN USB Type A |
| Expansion Slot(s) | 2 (total) / 2 (free) x EHWIC ¦ 2 (total) / 1 (free) x CompactFlash Card |
| Power | |
| Power Device | Power supply - internal |
| Voltage Required | AC 120/230 V ( 50/60 Hz ) |
| Miscellaneous | |
| Width | 34.3 cm |
| Depth | 29.2 cm |
| Height | 8.9 cm |
| Weight | 5.4 kg |
| Rack Mounting Kit | Included |
| Compliant Standards | CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, CS-03, R&TTE, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, BSMI CNS 13438, AS/NZS 3548 Class A, CAN/CSA C22.2 No. 60950-1, VCCI V-3, EN 61000, TIA/EIA/IS-968 |
| Software / System Requirements | |
| OS Provided | Cisco IOS IP Base |
| Manufacturer Warranty | |
| Service & Support | 1 year warranty |
| Service & Support Details | Limited warranty - 1 year |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 85% |
Related Products
--------------------------
Product Number |
Product Description |
Cisco 1941/K9 |
Cisco 1941 with 2 onboard GE, 2 EHWIC slots, 1 ISM slot, 256MB CF default, 512MB DRAM default, IP Base |
Cisco1941W-A/K9 |
Cisco 1941 Router w/ 802.11 a/b/g/n FCC Compliant, 2 onboard GE, 2 EHWIC slots, 256MB CF default, 512MB DRAM default, IP Base |
Cisco1941W-E/K9 |
Cisco 1941 Router w/ 802.11 a/b/g/n ETSI Compliant, 2 onboard GE, 2 EHWIC slots, 256MB CF default, 512MB DRAM default, IP Base |
Cisco1941W-P/K9 |
Cisco 1941 Router w/ 802.11 a/b/g/n Japan Compliant, 2 onboard GE, 2 EHWIC slots, 256MB CF default, 512MB DRAM default, IP Base |
Cisco1941W-N/K9 |
Cisco 1941 Router w/ 802.11 a/b/g/n Aus and NZ Compliant, 2 onboard GE, 2 EHWIC slots, 256MB CF default, 512MB DRAM default, IP Base |
Cisco1941W-C/K9 |
Cisco 1941 Router w/ 802.11 a/b/g/n China Compliant, 2 onboard GE, 2 EHWIC slots, 256MB CF default, 512MB DRAM default, IP Base |
