ISO Certificate Conveyor Roller/Return Roller/Impact roller for Conveyor System
Product Introduction
As one of National Innovation Fund Project, LIBO conveyor rollers are of complete sealing waterproof and dustproof design, whose bearing assembly employs high-precision bearing chamber and special bearings for idlers, which provide fine appearance, low noise, free maintenance, long service life(exceeding 50,000 hours) and high reliability. We invented controllable braking conveyor rollers, which can solve the problem of controllable brake along the line of large downward belt conveyors.
Advantage:
1. The rubber ring of impact conveyor rollers is made up of flame retardant rubber.
2.Stamping parts are used as bearing housing, which are machined by NC lathe;
3.The bearings are KA serial special bearing for rollers;
4.The material used for bearing shafts is high-strength 45#steel, and NC turning and grinding can ensure precision;
5.The sealing is specially designed with abilities of self-compensation, low resistance, waterproof and dustproof, which can keep bearing in good lubricated condition for a long time.
Basic Parameter of our roller
| Order | Parameter | Description |
| 1 | Brand | LBHI |
| 2 | Lift time | More than 50000 hours |
| 3 | Production capacity | as usual 600000/year. |
| 4 | Roller Diameter | 76-219mm(non-Standard supported) |
| 5 | Roller Length | 190mm to 3500mm |
| 6 | Roller tube | Q235 carbon steel,high-precision ERW,welded with DIN2394 Standard. |
| 7 | Shaft |
45# Cold drawing round steel in accordance withDIN17100 and other equivalent standard, ISO h6 precision |
| 8 | Bearing | Deep groove ball bearing 2RZ and 2Z with C3 clearance |
| 9 | Bearing brand | SKF, NSK,FAG, HRB, LYC, ZWZ etc. |
| 10 | Color | according to your requirement. |
| 11 | Finish | Ordinary painting/hot galvanized painting/rubber/steel screw/galvanized |
| 12 | Welding | Mixed gas shielded arc welding /Automatic CO2 gas shielding welding |
| 13 | Standard | ISO/BS/JIS/DIN//CEMA/Australia |
| 14 | Package | standard export plywood cases or iron cage with protective bubble film |
| 15 | suporting speed | Max speed 7m/s |
| 16 | Inspection | Professional inspection team |
Overview of rollers
Material and Bearing
Seal and structure
Product Equipment
Parameter
We offer the accurate technical and installation parameters that are feasible to our standard product to you so that you can make the best choices for the needs. If you have any special requirement for our product,Please let me know so as to send your needs to our engineer to deal with your problem by technical calculation on time. Above all,Please give us the accurate and comprehensive data about your project because the parameters are different according to multiple circumstances.It must makes you comfortable that we offer the professional high quality products to you.
