H.264 Support 4HDD Port 1.5U Chassis 16CH 960P NVR
Model NO.:DV8016
Key Features:
• P2P cloud service, including cloud connecting, cloud monitoring, cloud transmitting to access IPC and NVRat any time and any place
• Support Onvif protocol, support High profile S, High profile G, compatible with different IP camera that basedon Onvif, RTSP standard
• Support megapixel HD network video preview, storage and playback;
• Support search, playback and backup by event;
• Support all channel image display on one screen at same time, support 4 channels’ image display by mainstream,and 4 channels playback;
• Support monitor PTZ on preview mode
• Offer CMS for free
Technical Specification:
Model Number |
DV8016 |
|
Operating System |
Embedded LINUX operating system |
|
Image Code Control |
Image code quality adjustable, variable bitstream and constant bitstream optional |
|
Dual Stream |
Each channel can set main stream and sub stream |
|
Video Standard |
1080P(1920×1080)30fps/960P/(1280×960)/720P(1280×720)30fps |
|
Monitoring Image Quality |
1080P(1920×1080) / 960P/(1280×960)/720P(1280×720) |
|
Image Motion Detection |
Each screen can set multiple detection areas and set 6-level sensitivity |
|
Recording Playback Quality |
4ch 960P playback in 16ch 960P mode 1ch 1080P playback in 9ch 1080P mode |
|
Region Cover |
Every channel can set 4 cover regions(IPC Support) |
|
Recording Mode |
Support manual , auto, dynamic detection, alarm trigger record mode(Partly needs IPC Support) |
|
Backup Way |
Support U disk, USB mobile HDD, USB DVD-RW. network storage and backup |
|
Operation Way |
Mouse, remote control, front panel |
|
Local Login |
User name and password |
|
Recording Storage |
Local HDD, network |
|
|
External Ports |
Video Input |
16×(1280*960)+sub[640*480]+4Ref.+4Play 16ch 1.3MP IP Camera |
9x(1920*1080)+sub[960*576]+1Ref.+1Play 9ch 2.0MP IP Camera | ||
Audio Input |
16ch network audio input |
|
Video Output |
1ch VGA+1ch HDMI |
|
Audio Output |
1ch RCA output |
|
Network Port |
1 RJ45,10M/100M/1000M self-adaptive LAN port |
|
USB Port |
3 USB 2.0 ports (one on front panel, two on rear panel) |
|
Wireless Port |
3G,WIFI |
|
HDD |
HDD Port |
4 SATA HDD Port |
MAX Capacity |
Each port supports MAX 4TB HDD |
|
Mobile Surveillance |
Support( iPhone, Windows Mobile, BlackBerry, Symbian, Android) smart phone |
|
Power Supply |
12V6A |
|
Power Consumption |
≤25W(without HDD) |
|
Working Temperature |
-10℃~+55℃ |
|
Working Humidity |
10%-90% |
|
Dimension |
Equipment: 440mm×360mm×70mm, Packing: 460mm×135mm×560mm |
|
Installation Way |
Desktop Installation |
|
