8CH All In One LCD Monitor 16CH Mobile Phone Surveillance Real Time H.264 LCD DVR

8CH All In One LCD Monitor 16CH Mobile Phone Surveillance Real Time H.264 LCD DVR thumbnail-1
8CH All In One LCD Monitor 16CH Mobile Phone Surveillance Real Time H.264 LCD DVR photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Coop
Model Number:
HP-1608L Real Time H.264 LCD DVR
Contact Supplier Request Quote Chat Now
Coop Security Technology(Quanzhou)Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Quanzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Coop
Model Number HP-1608L Real Time H.264 LCD DVR

Specifications

Real Time H.264 LCD DVR
1.4/8ch Full real time
2.VGA,BNC,RCA
3. P2P
4.720P,1080P

8CH All In One LCD Monitor 16CH Mobile Phone Surveillance Real Time H.264 LCD DVR HP-1608L

8CH All In One LCD Monitor 16CH Mobile Phone Surveillance Real Time H.264 LCD DVR







Product Description



Real Time H.264 LCD DVR Features:

8CH All In One LCD Monitor 16CH Mobile Phone Surveillance Real Time H.264 LCD DVR

  • 15”LCD all-in-one Standalone DVR
  • Adopts the standard main profile H.264 compression technology,
  • D1 and CIF can be adjusted supports 8ch recording, Network transmission, and playback simultaneously
  • Support dual-stream transmission for all channels
  • Support Multiplex operation: live, record, playback, backup, network transmission, mobile phone surveillance
  • Support backup with USB Flash Disk, Movable hard disk, USB writer, Network
  • Support 1channel. Main output, 1channel. VGA output
  • Support video channel hidden and S.E.Q for single channel
  • Support Digital Zoom and PIP preview
  • Support password function to avoid data modification
  • Support Email alarm
  • Mobile phone surveillance (Win CE/ Symbian /iPhone/Blackberry)
  • Support PTZ preset and Cruise Control
  • Support Multi-language OSD
  • Central management software and Networked system management
  • Support mouse, remote controller, panel operating



Real Time H.264 LCD DVR Specification:

8CH All In One LCD Monitor 16CH Mobile Phone Surveillance Real Time H.264 LCD DVR

 Product Specifications

Main Function

HP-1608L

Operating system

Embedded Linux OS

Video Compression Format

Main Profile H.264

Video Input

8 Channels BNC

Video Output

1 Channel BNC ,1 Channel VGA(1280*1024)

Audio Input/Output

8 Channel RCA Input,1 Channel RCA Output

Display Picture

1/4/8CH

Digital Zoom,PIP

Supports

Multiplex Operation

LivedisplayPlaybackRecordingBackup

Mobile phone Surveillance Network simultaneously

Display Resolution

PAL:D1(704*576),NTSC:D1(704*480)

Recording Mode

ManualTimerMotion DetectionAlarm

Recording Frame Rate

PAL:D1@50fps,HD1@100fps,CIF@200fps

NTSC:D1@60fps,HD1@120fps,CIF@240fps

Recording Resolution

PAL:D1(704*576),HD1(704*288),CIF(352*288)

NTSC:D1(704*480),HD1(704*240),CIF(352*240)

Recording Playback

1/4/8channel playback simultaneously(Optional playback channel)

Recording Backup

USB,Moved Hard Disk,USB Writer,Network

Network transmission

8Channels real-time Network transmission with CIF resolution

Recording Play

Special player, Support AVI file format conversion

JPEG capture function

support,3M Pixels@10fps

Alarm input/output

8 channels input,1 channel output

Email Alarm

Send pieces to the designated email

PTZ

Supports PTZ preset ,Cruise Control and PC client port setup

PTZ protocol

PELCO-D,PELCO-P

HDD

Support 1 SATA HDD, capacity to 2TB

HDD Remain Time Hint

Support

Network and Protocol

1 RJ-45 10/100M via Ethernet, Support TCP/IP,PPPOE,DHCP,DNS,DDNS,NTP,UPNP

IE Browser

Windows XP/Vista/Win 7/Mac OS,IE6.0-9.0/Firefox/Chrome/Opera/Apple Safari

Client Software

Support

CMS

Support(One software for at most 100 DVRs ),Free supply to use

Dual Stream

Support(Main and secondary interchange)

Group play

At least Support five users online access

Privacy Mask

Support

S.E.Q

Support single channel and grouping S.E.Q

Watermark

Support

Multi-language

Support

Mobile Phone Surveillance

Support Windows Symbian iPhoneBlackberry Operation System

SDK Package

Available

Mouse Interface

USB2.0

Backup interface

USB2.0

Remote Controller

Support(Supports controller ID matching)

User Authority

Support Multi-level user authority distribution

DST

Support

Power

DC12V/5A

Working Temperature

0°C-50°C

Working Humidity

10%-90%

LCD Size

15 inch  4:3  CCFL  XGA









Company Information

COOP SECURITY(CHINA)LIMITED is one of the leading factories which develop and produce CCTV products in China, supported by the Chinese government as the most importantly developed company. All the models are produced by machine automatically.It has a Research and Development Center in Taiwan, possessing the most advanced patent for electronic R&D technique, leading us to be among the best in China.

8CH All In One LCD Monitor 16CH Mobile Phone Surveillance Real Time H.264 LCD DVR



Taipei International Show:

8CH All In One LCD Monitor 16CH Mobile Phone Surveillance Real Time H.264 LCD DVR



8CH All In One LCD Monitor 16CH Mobile Phone Surveillance Real Time H.264 LCD DVR


Packaging & Shipping

1. Transportation: UPS, TNT, DHL, EMS or FEDEX.

2. Item will be shipped out within 7 working days upon receipt of the payment.

3. Shipment may arrive within 5 – 16 days. Actual delivery days would be different for varies countries.

8CH All In One LCD Monitor 16CH Mobile Phone Surveillance Real Time H.264 LCD DVR


Our Services

1. Pls report us if there are any problem, we will solve it ASAP.

2. This items comes with 2 YEARS

8CH All In One LCD Monitor 16CH Mobile Phone Surveillance Real Time H.264 LCD DVR  8CH All In One LCD Monitor 16CH Mobile Phone Surveillance Real Time H.264 LCD DVR






FAQ

Q: How long your delivery time?

A: In general, the time is about one week.

Q: What’s your payment?

A: We accept payment by TT Bank Transfer in this stage.
