Support TVI 1080p cameras, 3.0MP IP cameras and older traditional analogue (CVBS) CCTV cameras TVI DVRs
NVR Recorder H.264 E-SATA VGA HDMI
Stabilization Workable for 552 days in high temp
Large capacity Admissible 8 Piece 4TB HDD
Central control IPC control by profession client
Easy operation 11 languages, whole icon, mouse operation
Vogue structure Flying Shuttle knob, cool appearance
*1ch BNC audio input, 1ch audio output
*Total network bandwidth is 128M
*4ch 720P HD playback simultaneously.
*support 9 SATA HDD
*support Onvif protocol
*support WIFI. 3G
36ch 720P High Definition NVR
*Optional: 25ch 1080P/16ch 1536P/9ch
*1920P input, Full real time
*HDMI .VGA output. BNC output additional.
F |
Model No. |
DV9009 |
DV9016 |
DV9036 |
General |
IPC Channel |
9 |
16 |
36 |
Image quality |
9 channel 720p 4 channel 1080p |
16channel 720p 9 channel 1080p |
36 channel 720p 16 channel 1080p |
|
Video Resolution |
720P(1280×720) or1080P(1920×1080) 1~30 frame/second optional |
|||
Recording Mode |
Support Manual record, timing record, motion detect record, alarming record |
|||
Playback quality |
Support 4 channel 720p(1280x 720)playback synchronous |
|||
Recording Save |
Local hard disk record, support different big size hard disk, 2TB, 3TB, 4TB etc. |
|||
Backup Type |
Support hard disk, U hard disk, Moved hard disk, USB writer, network storage and backup |
|||
IE |
IE browser |
Support LAN management, client management and remote IE visit |
||
Dual stream |
Alone Setting by each channel |
|||
Mobile Phone Surveillance |
Support (iPhone,Windows Mobile,BlackBerry,Symbian,Android) operation system |
|||
Wireless |
Support 3G and WIFI via USB port |
|||
Special |
Compatibility |
Can connect IP camera, IP speed dome camera and DVS. support Onvif2.0 protocol |
||
Mouse Zoom |
Click any area and zoom in or zoom out on the image by mouse |
|||
Motion Detection |
Each image can setting more area, Sensibility can setting by 6 grade |
|||
Search Way |
Support search, playback and backup by event |
|||
Video Quality |
Video Output |
Standard VGA HDMI type |
||
Video compression |
H.264 and MPEG-4 AVC |
|||
Video code control |
Image code quality adjustable, variable & certain stream optional |
|||
Audio Quality |
Audio Compression |
Standard G.711 |
||
Audio Input |
4 channel audio input |
|||
Audio Output |
1 channel RCA |
|||
Audio Talk |
Support 2 way audio talk back |
|||
Alarm |
Alarm Input |
4 Channel |
||
Alar Output |
1 Channel |
|||
External Port |
Video Output |
1ch VGA,1ch HDMI |
||
IP |
1pc RJ45 Ethernet port(10M/100M/1000M) |
|||
RS485 |
Full duplex RS485, Support 19 PTZ protocol |
|||
USB Port |
3 pcs USB2.0 standard port( Front and Back) |
|||
E-SATA |
2 pcs external ATA port |
|||
Disk Port |
8 Channel SATA port (HDD:2TB,3TB,4TB) |
|||
Power |
Power Parameter |
Voltage:AC110~240V Type:ATX Output Power:300W Frequency:50-60 Hz |
||
Consumption |
≤40W without hard disk |
|||
Other Standard |
Working Temperature |
-10 °C ~ +55 °C |
||
Working Humidity |
10%-90% |
|||
Weight(without Disk) |
(net) 6.58Kg, (gross) 9.50Kg |
|||
NVR Size |
(NVR) 440mm×450mm×90mm, (Packing) 539mm× 530mm×225mm |
|||
Carton Size |
2 sets/CTN, (2pcs/CTN Weight) 20.45Kg, (size) 555mm×545mm×470mm |
|||
Installing Type |
Table mode,equipment cabinet mode |
|||
