Completely new graphics operating interface design, to let you experience easily and conveniently.
>SDVR combines the functions of DVR/HVR/NVR together, multi-mode input support analog video, Analog HD video, network HD video input). No need to worry how to be compatible with analog system, to choose DVR or HVR, just one SDVR can work.
>Super Strong processing capacity: can realize 8CH AHD 1080N recording/8CH AHD 1080N realtime playback synchronously.
>Support main stream and extra steam encode synchronously. Main stream is for local storage to maintain the image quality, extra stream is for network real-time transmission, to easily solve the bottleneck problem of bandwidth.
>Support super cloud service (this function is optional, specialized website for super cloud service: ), one step to do remote control easily & conveniently without any complicated setting.
>Powerful net service(support DHCP,PPPOE,FTP,DNS,DDNS,ARSP(),NTP,UPNP,EMAIL,IP authority,IP search,alarm center, etc),complete enclosure(WEB,CMS,SDK),to easily achieve interconnection.
>Built-in IE plugs, no need to install from CD disk independently.
>Support 3G & WIFI extension.
>Support multi-browser(IE,Chrome,Firefox,Safari)
>Support kinds of mobile monitor(iPhone,, Android)
>Multiplex operation : Preview, recording, playback, backup, network live, mobile phone view; all operations are independent of each other.
>Support many recording modes: Auto-continuing recording, timing recording, motion detection recording.
>Playback mode support normal play, speed play, fast back play, manual and single-frame play.
>Many backup device: USB flash disk, USB portable HDD and network.
>Support alarm triggered recording will send alerts matter (some models support sending picture) to the designated email.
>Support pre-alarm recording (before 10 sec),not lose any suspicious screen.
>Twenty kinds of language(English,Finnish,French,German,Greek,Italian,Japanese,Polish,Portuguese,Russian,Spanish,Thai,Simplified Chinese,Chinese-Traditional,Turkish, etc),break up country limitation.
>System auto recovery to power after power reconnected, and return to the pre-power-down state
4CH HD 1080P TVI DVR Specification:
Model |
DV-8004-TVI |
DV-8008-TVI |
DV-8016-TVI |
||
System | |||||
Main Processor |
Embedded processor |
||||
Operating System |
Embedded LINUX |
||||
Video | |||||
Input |
4 channel, BNC |
8 channel, BNC |
16 channel, BNC |
||
Standard |
HDTVI |
4CH 720P HDTVI Camera |
|||
HDTVI |
4CH 1080P HDTVI Camera |
||||
Audio | |||||
Input |
1 channel,RCA |
||||
Output |
1 channel,RCA |
||||
Display | |||||
Interface |
1 HDMI, 1 VGA |
||||
Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768, 800×600 |
||||
Display Split |
1/4 |
1/4/8/9 |
1/4/8/9/16 |
||
Privacy Masking |
4 rectangular zones (each camera) |
||||
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
||||
Recording | |||||
Video/Audio Compression |
H.264/G.711 |
||||
Resolution |
1080P(1920×1080)/720P(1280×720)/960H(960×576/960×480)/D1/4CIF(704×576/704×480) / CIF(352×288/352×240) / QCIF(176×144/176×120) |
||||
Record Rate |
Main Stream: |
1080P(1~12/15fps)/720P/960H/D1/HD1/2CIF/CIF(1~25/30fps) |
|||
Extra Stream |
CIF/QCIF(1~25/30fps), D1(1~12/15fps) |
||||
Bit Rate |
48~4096Kb/s |
||||
Record Mode |
Manual, Schedule(Regular(Continuous), MD), Stop |
||||
Record Interval |
1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
||||
Video Detection | |||||
Trigger Events |
Recording, PTZ, Tour, Video Push, Email, FTP, Spot, Snapshot, Buzzer & Screen tips |
||||
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
||||
Playback & Backup | |||||
Sync Playback |
1/4 |
1/4/9 |
1/4/9/16 |
||
Search Mode |
Time/Date, MD & Exact search (accurate to second) |
||||
Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
||||
Backup Mode |
USB Device/Internal SATA burner/Network |
||||
Network | |||||
Ethernet |
RJ-45 port (10/100M) |
||||
Network Functions |
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P |
||||
Max. User Access |
128 users |
||||
Smart Phone |
iPhone, iPad, Android, Windows Phone |
||||
Storage | |||||
Internal HDD |
2 SATA port, up to 4TB |
||||
Auxiliary Interface | |||||
USB Interface |
2 ports(1 Rear), USB2.0 |
||||
RS485 |
1 port, For PTZ Control |
||||
General | |||||
Power Supply |
DC12V |
||||
Power Consumption |
10W(without HDD) |
||||
Working Environment |
-10°C ~+55°C / 10%~90%RH / 86~106kpa |
||||
Weight |
1.5KG(without HDD) |
||||
COOP SECURITY(CHINA)LIMITED is one of the leading factories which develop and produce CCTV products in China, supported by the Chinese government as the most importantly developed company. All the models are produced by machine automatically.It has a Research and Development Center in Taiwan, possessing the most advanced patent for electronic R&D technique, leading us to be among the best in China.
Taipei International Show:
1. Transportation: UPS, TNT, DHL, EMS or FEDEX.
2. Item will be shipped out within 7 working days upon receipt of the payment.
1. Pls report us if there are any problem, we will solve it ASAP.
2. This items comes with 2 YEARS
Q: How long your delivery time?
A: In general, the time is about one week.
Q: What’s your payment?
A: We accept payment by TT Bank Transfer in this stage.
