Specifications
wifi dimmable led panel1.Ultra thin: 13mm only.
2.Full size: 60*120,30*120,60*60,30*30,30*60,30*90cm
3.Warranty: 3 years
Shenzhen hot selling 50w 300x1200mm led panel lamp wifi dimmable lights
High power
Type No. |
Watt |
LED Type |
Lumen |
Actual Size(L*W*H) |
GL-PL-S300*300 |
20W |
Taiwan SMD |
814±10% |
295*295*13mm |
GL-PL-S300*600 |
28W |
Taiwan SMD |
1460±10% |
295*595*13mm |
GL-PL-S300*900 |
34W |
Taiwan SMD |
1860±10% |
295*895*13mm |
GL-PL-S600*600 |
43W |
Taiwan SMD |
3000±10% |
595*595*13mm |
GL-PL-S300*1200 |
50W |
Taiwan SMD |
3400±10% |
295*1195*13mm |
GL-PL-S600*1200 |
65W |
Taiwan SMD |
4500±10% |
595*1195*13mm |
Low power
Type No. |
Watt |
LED Type |
Lumen |
Actual Size(L*W*H) |
GL-PL-S300*300 |
15W |
Taiwan SMD |
700±10% |
295*295*13mm |
GL-PL-S300*600 |
20W |
Taiwan SMD |
1050±10% |
295*595*13mm |
GL-PL-S300*900 |
22W |
Taiwan SMD |
1350±10% |
295*895*13mm |
GL-PL-S600*600 |
32W |
Taiwan SMD |
2200±10% |
595*595*13mm |
GL-PL-S300*1200 |
33W |
Taiwan SMD |
2300±10% |
295*1195*13mm |
GL-PL-S600*1200 |
45W |
Taiwan SMD |
3200±10% |
595*1195*13mm |
Electrical Parameters:
LED Panel Output Voltage: 26-30Vdc
External Driver Input Voltage: 90-240Vac
Frequency: 50/60Hz
Optical Parameters:
Light Efficiency: 75-85LM/W
Color Temperature: Pure white-5500-6500K, Warm white-4000-4500k, Amber white-2700-3500k.
Other Parameters:
Product Patents: Yes
Operating Temperature: 0°C-35°C
Appearance: Frosted
Main Material: Aluminum Alloy+ Optical PMMA
IP Rating: IP40
Life Span: 50,000hours
Application: Hotel, supermarket, office, building, Gym centre,shop, hospital...
Warranty: 3 years
Cable between panel and driver
Driver
Application
Taiwan SMD
5500
