plastic bucket mould tooling mold

plastic bucket mould tooling mold

 Injection Molded R&D Products

 Inspiring, new product ideas are everywhere for R&D-minded companies and entrepreneurs. Taking those ideas and turning them into reality is also one of Yixun's inspirations.

 Our team has the design knowledge, engineering and manufacturing experience needed to bring your injection molded concepts to life. From co-development of R&D products, through full plastics production, yixun  Molded Plastics is committed to providing the highest quality products and services the first time, on-time.

 Why bring your R&D project to Yixun?

 Production Quality Prototypes - YX can develop prototype tools that are effective, low-volume production tools

• Melt Flow Analysis - YX’s design specialists can use simulation software to optimize the product design and manufacturing process before the first piece of steel is cut, which reduces the time needed to condition the mold and speeds the product to market
• In-Process Monitoring - YX is using the latest in process monitoring systems and pressure sensing technology to ensure consistency, maximum up-time and quality in the production line
• Integrated Assembly, Automation and Packaging - YX Molded Plastics excels at finding innovative ways to assemble, automate, sort by cavity ID, and package finished products to reduce costs and build value into the production process
• Secondary Services - YX will gladly evaluate and offer solutions that meet your needs for special processessuch as de-burring, post-curing, or sonic weldingVV
• Mold Design Resources and Tools at Yixun
• Our design team at yixun Molded Plastics uses project management fundamentals throughout the design process to document customer specific requirements and integrate them into the mold product design. Using parametric fundamentals of design, the team creates tool design models that have complete associativity throughout all of the different components of an assembly.  Some of our design tools and resources include:

Primary CAD Software

PTC (Creo 2.0 or earlier)

Siemens (NX 8.0 or earlier)

Primary CAM Software

Pro/NC for high-speed precision machining of cores/cavities and electrodes

DP Esprit for CNC wire EDMs

Design and Engineering Experience

Shuttle and insert molds

Face-mounted, quick-change tooling

Expandable and interchangeable tooling

Multiple slide action molds

Stripper and floating cavity plate molds

Hot runner system

Unscrewing molds

Sending file for quotation :

Engineering File Preparation

Yixun Molded Plastics provides design assistance, engineering services and complete project management for precision injection molded plastics products through out the design, custom mold build, plastics production and often includes other value added services.  If you have an idea or a project that you would like to see take shape contact our team today!

RFQ File Formats

Pro /Engineer (Wildfire 3 or earlier)

Unigraphics (NX3 or earlier)

Parasolids

STEP

IGES

DXF

AutoCAD (Rev.14)

 If available, please include:

3D engineering file and/or 2D print

Resin type and color

Type of finish

Anticipated yearly part volume(s)

Advanced Equipment

For Mold Making:

Latest Equipment List:

Plastic Injection

We also good at produce all kinds of plastic product as your customised Mould.

Injection Equipment:

Choosing the Best Resin for Your Part

The success of innovative design and engineering rely on choosing the right material for your project.  Our specialists at Yixun Molded Plastics have the knowledge around the nuances of the various engineering resins available.  We will guide you in choosing an appropriate resin that will result in a quality and effective injection molded plastic product.

PPS  (Polyphenylene Sulfide)

Examples – Ryton, Fortron

• Aviation and electronics high-temp environments
• Stability for temp changes
• Tolerancing in steel is critical for close-tolerance molded product
• Very tight process window
• Stringent PM guidelines on molds and screw and barrel
• Thick/thin wall variation can be molded together, but requires adequate design for manufacturing analysis with moldflow and fill simulation technology
• Highly susceptible to flash
• Medical, healthcare, sporting goods
• Extremely pliable Shore A 00 Durometer requires non-typical molding press screw design and processing standards
• Part-removal and ejection techniques are non-standard for mold build and may require automation or operator assistance
• TPE  (Thermoplastic Elastomer)

Quality control

Total Quality Management

3D Measurement of mold parts checking

YIXUN QC procedure:

1: Part mold draft analysis,

2:Mold design control,

3:steel hardness inspection,

4:Dimension inspection of electrode cavity and core,

5:Mold trial report and inspection report

6:Shipment inspection

Certifications

Client's visit

We always say the warmest welcome to all friends from all over the world.

Client feedback
