Brass Wire Mesh Factory

Brass Wire Mesh Factory thumbnail-1
Brass Wire Mesh Factory photo-1
US$ 8 - 14 MOQ: 1000 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
KAH
Model Number:
brass wire mesh
Contact Supplier Request Quote Chat Now
Beijing Keaohua Metal Products Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
xingang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name KAH
Model Number brass wire mesh
Material Other, Brass Wire, Brass Wire
Application Sieving Diversified Pellet
Type Other, Plain weave, twill weave or Dutch weave.
Mesh Size 6 mesh to 120 mesh

Specifications

1.Material: Brass wire, phosphor bronze wire,copper wire
2.120mesh-360mesh/inch
3.Width:0.914M, 1M, 1.5M
4.Length/roll:30m

BRONZE WIRE MESH/ Brass Wire Mesh



Materials: brass wire, Phosphor bronze wire and copper wire.



Specifications: brass wire mesh from 6-200mesh, copper wire cloth 10mesh/inch-60mesh/inch; phosphor bronze wire cloth 120mesh-360mesh/inch .
Width:0.914M, 1M, 1.5M

Length/roll:30M





Weaving Type: Plain Weave, Twill Weave, and Dutch-Plain Weave


Features: Brass Wire Mesh is also named Brass Wire Cloth, it has better abrasion resistance, better corrosion resistance, higher strength and lower electrical conductivity.




Application: Brass Wire Mesh is used in sieving diversified pellet, powder, porcelain clay and glass, chinaware printing, filtering liquid and gas.





Mesh
Wire Dia.
Opening(mm)
SWG mm inch
6mesh 22 0.711 0.028 3.522
8mesh 23 0.610 0.024 2.565
10mesh 25 0.508 0.020 2.032
12mesh 26 0.457 0.018 1.660
14mesh 27 0.417 0.016 1.397
16mesh 29 0.345 0.014 1.243
18mesh 30 0.315 0.012 1.096
20mesh 30 0.315 0.0124 0.955
22mesh 30 0.315 0.0124 0.840
24mesh 30 0.315 0.0124 0.743
26mesh 31 0.295 0.0116 0.682
28mesh 31 0.295 0.0116 0.612
30mesh 32 0.247 0.011 0.573
32mesh 33 0.254 0.010 0.540
34mesh 34 0.234 0.0092 0.513
36mesh 34 0.234 0.0092 0.472
38mesh 35 0.213 0.0084 0.455
40mesh 36 0.193 0.0076 0.442
42mesh 36 0.193 0.0076 0.412
44mesh 37 0.173 0.0068 0.404
46mesh 37 0.173 0.0068 0.397
48mesh 37 0.173 0.0068 0.356
50mesh 37 0.173 0.0068 0.335
60meshx50mesh 36 0.193 0.0076 -
60meshx50mesh 37 0.173 0.0068 -
60mesh 37 0.173 0.0068 0.250
70mesh 39 0.132 0.0052 0.231
80mesh 40 0.122 0.0048 0.196
90mesh 41 0.112 0.0044 0.170
100mesh 42 0.012 0.004 0.152
120meshx108mesh 43 0.091 0.0036 -
120mesh 44 0.081 0.0032 0.131















Brass Wire Mesh Factory



Brass Wire Mesh Factory



Brass Wire Mesh Factory



 Brass Wire Mesh Factory



Brass Wire Mesh Factory



Brass Wire Mesh Factory



Brass Wire Mesh Factory



Brass Wire Mesh Factory



Brass Wire Mesh Factory



Brass Wire Mesh Factory



Brass Wire Mesh Factory



Brass Wire Mesh Factory



Brass Wire Mesh Factory



Brass Wire Mesh Factory



Brass Wire Mesh Factory
