300w/220v Hot Sales Automatic Small Laser Spot Welder Machines Factory
Widely used in aviation, machinery, electronics, communication, energy, chemical, automobile manufacture, welding of automobile parts, hydraulic lever, gasoline filter, automobile tail gas sensor, solenoid valve and start motor stator, and seal welding lithium battery.
Precision spot welding and seal welding of mobile phone battery, energy battery, metallurgy (welding of silicon steel plate), military industry sensor, motor blade welding electronic components, welding of (relay) electric apparatus industry, silicon steel plate, air conditioner motor rotor, leakage protector
Model No. |
W500HZ, WF500HZ |
Machinery Part |
Optical system moves 800mm distance and laser head can 360° rotate |
Bench Stroke |
Working area 750*1000 |
Working table material |
30mm marble table |
Bearing of bench |
≤200KG |
Power supply |
220V±10%/50/60Hz or 380V±10%/50/60Hz |
Laser type |
Pulsed Nd:YAG (Xenon lamp) |
Adjustment range of light spot |
0.1~0.3mm |
Size of light spot |
0.2~3.0mm |
Operation mode |
Standard mode (W500HZ) Standard mode and fiber handle weld double use (WF500HZ) |
Laser wavelength |
1064nm |
Pulse width |
≤15ms |
Max laser power |
500W |
Pulse frequency |
≤50Hz |
Laser output |
200mm |
Laser cooling |
Water cooling |
refrigerating capacity |
5000w |
Total power |
<11KW |
Observation system |
CCD( microscope for option) |
materials |
all metals: stainless steel, iron plate, galvanized sheet, aluminum letters, copper and so on |
1, How to pay to you ?
T/T inadvance or by Others . We can accept 30% deposit , and balance paid to us before delivery machine to you .
2, How long is the delivery time?
For standard machines, it would be 15 days; For non-standard machines and customized machines according to clients specific requirements.
3. I want a size that you don`t make as standard, is this possible?
Absolutely, we can design and manufacture any size our clients require.
4. I am new to CNC, how difficult are your machines to operate?
We help a lot of beginners in CNC, if you have a reasonable knowledge of computers and are willing to spend a little time learning it is not that bad.We can also offer installation and operator training service upon request. Clients have to responsible for the expenses on traveling, food and accommodation.
5. How do you send your CNC machine?
They are firstly packaged in wooden case. Usually, we send machine by ship, sometimes, as customer's requirement, send by air or by train. When the goods arrive at your sea port or destination, you can pick up goods with the bill of lading we offered. Or we can arrange the cargo agent to send goods to you.
If you have some questions , pls don't hesitate to contact us , we will give you best price !
